| Summary |
Features
Designed to be noticed: Metal front panel with custom TUF Gaming spatter pattern, and 4mm-thick, smoked, tempered-glass side panel to showcase your build’s internals.
Mobile battle station: Ergonomic, woven-cotton carry handles enable easy and safe transport up to 30Kg.
Efficient cooling: Equipped with three 120mm Aura Sync RGB-illuminated fans and one 140mm rear PWM fan, plus up to seven fan-mounting points for targeted airflow.
Space reserved for both front- and top-mounted 360mm water-cooling radiators plus a 140mm radiator at the rear.
Perfect for TUF Gaming motherboards: Fan and cable placement optimized for TUF Gaming gear, and ready for perfect cooling control via our Fan Xpert 4 software.
ASUS TUF Gaming GT501 Case Overview
ASUS TUF Gaming GT501 Case Designed Metal front panel with custom TUF Gaming spatter pattern, and 4mm-thick, smoked, tempered-glass side panel to showcase your build’s internals. ASUS TUF Gaming GT501 Case Ergonomic, woven-cotton carry handles enable easy and safe transport up to 30Kg. ASUS TUF Gaming GT501 Case Equipped with three 120mm Aura Sync RGB-illuminated fans and one 140mm rear PWM fan, plus up to seven fan-mounting points for targeted airflow. Space reserved for both front- and top-mounted 360mm water-cooling radiators plus a 140mm radiator at the rear. ASUS TUF Gaming GT501 Case Fan and cable placement optimized for TUF Gaming gear, and ready for perfect cooling control via our Fan Xpert 4 software
AURA LIGHTING WITH VENTILATION
TUF Gaming GT501's trio of 120mm Aura Sync RGB fans each contains 11 blades and delivers high-static pressure flow for targeted cooling. There's also a high-airflow 140mm PWM fan for wider heat removal.
THE PERFECT COMBINATION OF CAST ALLOY & FABRIC HANDLES
It's fitted with two ergonomic, woven-cotton handles, rigorously tested to support up to 30kg – so it's both easy and safe to transport your completed build.
Cooling Fan Design
It's easy to upgrade cooling when you need it, with up to seven mounting points for the installation of fans.
TOTAL SOLUTION FOR ANTI-DUST
The magnetic dust filter on top and front for a tight seal, and quick removal and cleaning. Slide-out dust filter at the bottom to enable easily fast maintenance.
.. |
Type
Mid Tower
Tempered Glass Panel
Left Side
Motherboard Support
EATX (12"x10.9"), ATX, Micro-ATX, Mini-ITX
Color(s)
Grey
Weight
10.5 Kg
Dimensions
552 x 251 x 545 mm
Front Ports
1 x Headphone
1 x Microphone
2 x USB 3.1 Gen1
Expansion Slots
7 expansion slots space
2 (additional vertical)
Radiator Support
Front: 120 mm, 140 mm, 240 mm, 280 mm, 360 mm
Top: 120 mm, 140 mm, 240 mm, 280 mm, 360 mm
Rear: 120 mm, 140 mm
Fan Support
Front: 3 x 120 mm, 2 x 140 mm
Top: 3 x 120 mm, 2 x 140 mm
Rear: 1 x 120 mm, 1 x 140 mm
Pre- Installed Fans
Front: 3 x 120 mm RGB
Rear: 1 x 140 mm PWM
Drive Bays
3 x 2.5" Bay
4 x 2.5"/3.5" Combo Bay
PSU
240mm
Side Panel
Tempered Glass
Maximum Processor Cooler Height
180mm
Maximum Graphics Card Length
420mm
Warranty
No Warranty
Asus TUF Gaming GT501 Mid Tower Gaming Casing Grey
TUF Gaming GT501 is crafted from up to 1.5mm-thick galvanized steel for enhanced durability in understated industrial style, and has a special coating that resists scuffs and scratches. It's fitted with two ergonomic, woven-cotton handles, rigorously tested to support up to 30kg – so it's both easy and safe to transport your completed build. With a full-height, smoked-glass side panel, TUF Gaming GT501 lets you show off your build from top to bottom – so your components, customizations and Aura illuminations are all clearly visible. This panel is tempered for strength, and hinged at the bottom for opening ease. Fitted RGB-enabled fans enable to work with the Aura-supported motherboards. With exclusive ASUS Aura Sync lighting technology, TUF Gaming GT501 provides ambient lighting that can be synchronized with other Aura Sync-enabled components. TUF Gaming GT501's trio of 120mm Aura Sync RGB fans each contains 11 blades, and deliver high-static-pressure flow for targeted cooling. There's also a high-airflow 140mm PWM fan for wider heat removal. It's also easy to upgrade cooling when you need, with up to seven mounting points for the installation of additional fans. TUF Gaming GT501 makes PC DIY easier than ever. Integrated cable-management ensures neatness, while pre-installed physical supports for the motherboard eliminates additional costs and mean you're ready to build from the get-go. It all adds up to design with you in mind for an unrivalled PC-building experience. Removable dust filters effectively prevent airborne particulates from entering TUF Gaming GT501, keeping your system's internals looking as good as new for longer. The top and front filter are magnetic for a tight seal, and quick removal and cleaning, while the lower dust-trap is easily slid in and out to enable fast maintenance.
.. |
