DeepCool CH160 MESH mini tower case(White)










- Stock: In Stock
- Brand: DeepCool
- Model: CH160 MESH-WH
Key Features
- Type: Tower housing
- Power supply type: ATX
- Dimensions Width: 20cm x Height: 28.35cm x Depth/Length: 33.6cm
- Material: Steel, Plastic
Generel information | |
Type | Tower housing |
Color | White |
Connection | 1x Audio connection, 2x USB-A 3.2 Gen 1 (5 Gbps), 1x USB-C 3.2 Gen 2 (10 Gbps) The name USB 3.2 (5 Gbit/s) is the new name for USB 3.1 Gen 1 and USB 3.0. The name USB 3.2 (10 Gbit/s) is the new name for USB 3.1 Gen 2 and USB 3.1. |
Dimensions | Width: 20cm x Height: 28.35cm x Depth/Length: 33.6cm |
Form Factor | Mini Tower |
Material | Steel, Plastic |
VOLUME | 19 l |
Water Cooling Support | Yes |
Weight | 3.1 kg |
Others | Motherboard form factor: Mini-ITX Mesh Front: Yes Internal dimensions Graphics card length: maximum 230 mm CPU cooler height: maximum 172 mm Power supply type: ATX Length of power supply: maximum 140 mm Lock openings: Full-size slots, 3 piece(s) Front: Space for 1x 120 mm fan, not to be used if location is in use by 2.5 SSD / 3.5 HDD Backside: Space for 1x 120 mm fan Particulars: Space for 2x 120 mm fans on the top Space for 2x 120 mm fans on the side Three removable dust filters Motherboard reverse connector: No Accessories: Optional (not included),DeepCool PIXEL bits |
Warranty Information | |
Warranty | No Warranty |
DeepCool CH160 MESH mini tower case(White)
DeepCool CH160 MESH Mini Tower Case is a compact yet powerful solution designed for modern PC builders who seek functionality, aesthetics, and efficient cooling in a small form factor. With its sleek black steel and plastic construction, this mini tower case offers durability and style, while its mesh front panel ensures superior airflow to keep your system cool and running smoothly.This case is tailored for Mini-ITX motherboards, making it ideal for compact builds without compromising performance. It supports graphics cards up to 230mm in length and CPU coolers with a maximum height of 172mm, allowing you to install high-performance components effortlessly. The case also accommodates ATX power supplies up to 140mm in length, ensuring compatibility with a range of options.For storage, the CH160 MESH provides two 2.5" drive bays, allowing you to set up an efficient storage system. It features three full-size slots for expansion, making it flexible for additional upgrades. The front panel connections include one USB-C 3.2 Gen 2 port, two USB-A 3.2 Gen 1 ports, and an audio jack, offering convenient and fast access to peripherals and devices.The case is optimized for cooling, with space for multiple fan configurations. It supports one 120mm fan at the back, two 120mm fans on the side, and two 120mm fans on the top, ensuring excellent airflow. Additionally, it offers support for 240mm radiators on the side for water cooling setups. The removable dust filters keep your system clean and efficient.With its compact dimensions of 20cm x 28.35cm x 33.6cm and lightweight design at 3.1kg, the CH160 MESH is easy to handle and transport. This case is perfect for those looking to build a high-performance system in a sleek, space-saving design.
Features
- Compact mini-tower design with durable steel and plastic build.
- Mesh front panel for enhanced airflow and cooling efficiency.
- Supports Mini-ITX motherboards for space-saving builds.
- Accommodates GPUs up to 230mm and CPU coolers up to 172mm.
- Flexible cooling options with space for up to five fans.
- Supports 240mm radiators for water cooling on the side.
- Convenient front I/O ports: USB-C 3.2 Gen 2, USB-A 3.2 Gen 1, and audio jack.
- Three removable dust filters for easy maintenance.
- Lightweight and compact, ideal for portable PC setups.
