GIGABYTE AMD B550M GAMING X WIFI6 Motherboard
- Stock: In Stock
- Brand: Gigabyte
- Model: B550M GAMING X WIFI6
Key Features
- Socket Type: AMD AM4
- Supported CPU: AMD Ryzen™ 5000/4000/3000 Series
- Memory Support: Dual Channel DDR4 up to 128 GB with XMP
- Storage: 2×M.2 PCIe 4.0/3.0 slots + 4×SATA 6Gb/s ports with RAID support
| Main Features | |
| Chipset | AMD B550 |
| General Information | |
| Audio | Realtek® ALC1220 CODEC * The back panel line out jack supports DSD audio. High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. |
| CPU | AMD Socket AM4, support for: AMD Ryzen™ 5000 G-Series Processors/ AMD Ryzen™ 5000 Series Processors/ AMD Ryzen™ 4000 G-Series Processors/ AMD Ryzen™ 3000 G-Series Processors/ AMD Ryzen™ 3000 Series Processors (Go to GIGABYTE’s website for the latest CPU support list.) |
| Expansion Slots | 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU: – AMD Ryzen™ 5000/3000 Series Processors support PCIe 4.0 x16 mode – AMD Ryzen™ 5000 G/4000 G/3000 G Series Processors support PCIe 3.0×16 mode * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset: – 1 x PCI Express x16 slot (PCIEX4), supporting PCIe 3.0 and running at x4 – 1 x PCI Express x1 slot (PCIEX1), supporting PCIe 3.0 and running at x1 |
| Internal I/O Connectors | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x CPU fan header 2 x system fan headers 2 x addressable LED strip headers 2 x RGB LED strip headers 1 x CPU cooler LED strip/RGB LED strip header 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C® header, with USB 3.2 Gen 1 support 1 x USB 3.2 Gen 1 header 1 x USB 2.0/1.1 header 1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only) 1 x serial port header 1 x Clear CMOS jumper 1 x Q-Flash Plus button Back Panel Connectors 2 x USB 2.0/1.1 ports 1 x PS/2 keyboard/mouse port 1 x HDMI port (Note) 1 x DisplayPort (Note) 4 x USB 3.2 Gen 1 ports 1 x RJ-45 port 2 x antenna connectors 3 x audio jacks (Note) Actual support may vary by CPU. I/O Controller iTE® I/O Controller Chip H/W Monitoring Voltage detection Temperature detection Fan speed detection Overheating warning Fan fail warning Fan speed control * Whether the fan speed control function is supported will depend on the fan you install. BIOS 1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 Unique Features Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. – @BIOS – EasyTune – RGB Fusion – Smart Backup – System Information Viewer Support for Q-Flash Plus Support for Q-Flash Bundled Software Norton® Internet Security (OEM version) LAN bandwidth management software Operating System Support for Windows 11 64-bit Support for Windows 10 64-bit Form Factor Micro ATX Form Factor; 24.4cm x 24.4cm |
| LAN | Realtek® GbE LAN chip (1 Gbps/100 Gbps/10 Mbps) |
| Memory | 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)of system memory Support for DDR4 3200/2933/2667/2400/2133 MT/s memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for Extreme Memory Profile (XMP) memory modules (The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to “Memory Support List” on GIGABYTE’s website for more information.) |
| Onboard Graphics | Integrated Graphics Processor with AMD Radeon™ Graphics support: – 1 x DisplayPort, supporting a maximum resolution of 5120×2880@60 Hz * Support for DisplayPort 1.4 version, HDCP 2.3, and HDR. – 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz * Support for HDMI 2.1 version, HDCP 2.3, and HDR. ** Support for native HDMI 2.1 TMDS compatible ports. (Graphics specifications may vary depending on CPU support.) Maximum shared memory of 16 GB |
| Storage Interface | 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 2280 SSDs: – AMD Ryzen™ 5000/3000 Series Processors support SATA and PCIe 4.0×4/x2 SSDs – AMD Ryzen™ 5000 G/4000 G/3000 G Series Processors support SATA and PCIe 3.0 x4/x2 SSDs 1 x M.2 connector (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type 2280 SATA and PCIe 3.0 x2 SSDs 4 x SATA 6Gb/s connectors RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, and RAID 10 support for SATA storage devices |
| USB | CPU: – 4 x USB 3.2 Gen 1 ports on the back panel Chipset: – 1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header – 2 x USB 3.2 Gen 1 ports available through the internal USB header – 4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header) |
| Wireless Communication module | Realtek® Wi-Fi 6 RTL8851BE – WIFI a, b, g, n, ac, ax, supporting 2.4/5 GHz carrier frequency bands – BLUETOOTH 5.3 – Support for 11ax 80MHz wireless standard (Actual data rate may vary depending on environment and equipment.) |
| Warranty Information | |
| Warranty | 3 years |
GIGABYTE AMD B550M GAMING X WIFI6 Motherboard
The GIGABYTE AMD B550M GAMING X WIFI6 Motherboard is a high-performance Micro ATX board designed for gamers, content creators, and PC enthusiasts seeking speed, reliability, and versatile connectivity. Built on the AMD B550 chipset with an AM4 socket, it supports AMD Ryzen™ 5000, 4000 G-Series, and 3000 Series processors, delivering future-ready performance for gaming, multitasking, and creative workloads. It features four DDR4 DIMM slots supporting up to 128 GB memory at speeds up to 3200 MT/s, with dual-channel architecture and XMP profiles for optimized memory performance. Integrated graphics support includes DisplayPort 1.4 (5120×2880@60 Hz) and HDMI 2.1 (4096×2160@60 Hz), while the Realtek® ALC1220 codec provides up to 7.1-channel high-definition audio. Networking combines Realtek® GbE LAN and Wi-Fi 6 with Bluetooth 5.3 for stable wired and wireless connectivity. Storage options include two M.2 slots (PCIe 4.0/3.0) and four SATA 6Gb/s ports with RAID 0, 1, and 10 support. Expansion slots feature PCIe 4.0 x16, PCIe 3.0 x16 (x4 mode), and PCIe 3.0 x1 slots for graphics cards and additional components. Connectivity includes USB 3.2 Gen 1, USB Type-C®, and USB 2.0 ports. RGB headers, multiple fan headers, and hardware monitoring provide customizable lighting, advanced cooling, and system stability.
Crystal-Clear Visuals and Powerful Memory Support
The GIGABYTE AMD B550M GAMING X WIFI6 delivers ultra-sharp 4K visuals via DisplayPort 1.4 and HDMI 2.1 while supporting DDR4 memory up to 128 GB for high-speed gaming and multitasking.
Seamless Connectivity and Storage Expansion
Dual M.2 slots and four SATA ports with RAID support provide flexible, high-speed storage solutions. USB 3.2 Gen 1 and Type-C® ports ensure versatile peripheral connectivity.
Reliable Networking and Superior Audio
Equipped with Wi-Fi 6, Bluetooth 5.3, and Realtek® GbE LAN, the motherboard offers stable wired and wireless connections. The Realtek® ALC1220 codec delivers immersive 7.1-channel high-definition audio.
Why Choose the GIGABYTE AMD B550M GAMING X WIFI6?
- Supports AMD Ryzen™ 5000/4000/3000 Series processors
- High-speed DDR4 memory up to 128 GB with XMP support
- Dual M.2 slots and four SATA ports with RAID 0/1/10 support
- 4K-ready DisplayPort 1.4 and HDMI 2.1 graphics output
- Wi-Fi 6, Bluetooth 5.3, and Realtek® GbE LAN connectivity
- 7.1-channel HD audio with Realtek® ALC1220 codec
- Customizable RGB lighting and advanced cooling options
- Micro ATX form factor with compact and durable design
Buy Now GIGABYTE AMD B550M GAMING X WIFI6 Motherboard at Ultra Technology
The GIGABYTE AMD B550M GAMING X WIFI6 Micro ATX Motherboard, available at Ultra Technology, combines DDR4 performance, PCIe 4.0 storage support, Wi-Fi 6, Bluetooth 5.3, and advanced connectivity in a compact, durable design. Ideal for gamers, creators, and professionals seeking a powerful and versatile platform.
