MSI B550M Pro-VDH AMD AM4 DDR4 Micro-ATX Motherboard

MSI B550M Pro-VDH AMD AM4 DDR4 Micro-ATX Motherboard
MSI B550M Pro-VDH AMD AM4 DDR4 Micro-ATX Motherboard
MSI B550M Pro-VDH AMD AM4 DDR4 Micro-ATX Motherboard
MSI B550M Pro-VDH AMD AM4 DDR4 Micro-ATX Motherboard
-19 %
MSI B550M Pro-VDH AMD AM4 DDR4 Micro-ATX Motherboard
MSI B550M Pro-VDH AMD AM4 DDR4 Micro-ATX Motherboard
MSI B550M Pro-VDH AMD AM4 DDR4 Micro-ATX Motherboard
MSI B550M Pro-VDH AMD AM4 DDR4 Micro-ATX Motherboard
MSI B550M Pro-VDH AMD AM4 DDR4 Micro-ATX Motherboard
Special Price: 14,200৳
Regular Price: 17,500৳
14,200৳
17,500৳
Ex Tax: 14,200৳
EMI starts at 4,979৳/month. View all 27 banks EMI plans >
  • Stock: In Stock
  • Brand: MSI
  • Model: B550M Pro-VDH

Key Features

    • Supports AMD Ryzen 5000 & 3000 Series Processors
    • PCB with 2OZ Thickened Copper
    • Supports DDR4 Memory, up to 4400(OC) MHz
    • PCIe 4.0, Lightning Gen4 x4 M.2 with M.2 Shield Frozr
Contact for Bulk Quantity: 01771833944
অর্ডার করার পূর্বে কাস্টমার কেয়ার থেকে পন্যের স্টক ও ডেলিভারি সম্পর্কে জেনে নেয়ার অনুরোধ করা যাচ্ছে। প্রযুক্তি পণ্যের মূল্য অস্থিতিশীল হওয়ায় কারণে যেকোন মুহূর্তে যেকোন প্রযুক্তি পণ্যের মূল্য পরিবর্তন হতে পারে।
General Information
Type Dual-channel memory architecture
Audio Realtek ALC892 Codec
7.1-Channel High Definition Audio
Display Port (s) 1x DisplayPort supports a maximum resolution of 4096x2160 @60Hz
Form Factor Micro-ATX Form Factor
9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)
Graphics 1x VGA port, supports resolution of 2048x1536 @50Hz, 2048x1280 @60Hz, 1920x1200 @60Hz
1x DisplayPort, supports a maximum resolution of 4096x2160 @60Hz
1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz
M.2 Socket 2x M.2 slots (Key M)
M2_1 slot (from AMD Processor)
Supports PCIe 4.0/ 3.0 x4
Supports SATA 6Gb/s
Supports 2242/ 2260/ 2280 storage devices
M2_2 slot (from AMD B550 chipset)
Supports PCIe 3.0x4
Supports 2242/ 2260/ 2280 storage devices
PCI 1x PCIe 4.0/ 3.0 x16 slot (PCI_E1)
2x PCIe 3.0 x1 slots
Slots 4x DDR4 memory slots
TPM (Trusted Platform Module ) 1 x TPM module connector
Main Features
Chipset AMD B550
Supported CPU Supports AMD Ryzen 5000 & 3000 Series desktop processors (not compatible with AMD Ryzen 5
3400G & Ryzen 3 3200G) and AMD Ryzen 4000 G-Series desktop processors
Graphics Specifications
Max Shared Memory 16GB
Memory Specifications
Maximum Memory 128GB
Supported Memory Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC
Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133
/4266 /4400+ MHz by A-XMP OC MODE
1DPC 1R max speed 4400 MHZ
1DPC 2R max speed 3733 MHZ
2DPC 1R max speed 3866 MHZ
2DPC 2R max speed 3466 MHZ
Supports non-ECC UDIMM memory
Supports ECC UDIMM memory
Supports un-buffered memory
Connector & ports
HDMI 1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz
Internal I/O Ports 1x 24-pin ATX main power connector
1x 8-pin ATX 12V power connector
4x SATA 6Gb/s connectors
2x M.2 slots (M-Key)
1x USB 3.2 Gen 1 5Gbps Type-C port
1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports)
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1x 4-pin CPU fan connector
1x 4-pin water-pump fan connector
3x 4-pin system fan connectors
1x Front panel audio connector
2x System panel connectors
1x Serial port connector
1x Chassis Intrusion connector
2x 4-pin RGB LED connectors
2x 3-pin RAINBOW LED connectors
1x Clear CMOS jumper
LAN Port (s) 1x Realtek 8111HN Gigabit LAN controller
Supported Storage AMD B550 Chipset
4x SATA 6Gb/s ports
2x M.2 slots (Key M)
M2_1 slot (from AMD Processor)
Supports PCIe 4.0/ 3.0 x4
Supports SATA 6Gb/s
Supports 2242/ 2260/ 2280 storage devices
M2_2 slot (from AMD B550 chipset)
Supports PCIe 3.0x4
Supports 2242/ 2260/ 2280 storage devices
USB (s) AMD B550 Chipset
3x USB 3.2 Gen 1 5Gbps ports (1 Type-C internal connector, and 2 ports are available through
the internal USB 3.2 Gen 1 5Gbps connector)
6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0
connectors)
AMD Processor
4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel
Warranty Information
Warrantty 03 Years Warranty

MSI B550M Pro-VDH AMD AM4 DDR4 Micro-ATX Motherboard

MSI B550M Pro-VDH AMD AM4 DDR4 Micro-ATX Motherboard is designed to deliver powerful performance and versatility, making it an excellent choice for gamers, content creators, and professionals. Built with AMD’s B550 chipset, this motherboard supports AMD Ryzen 5000 & 3000 Series desktop processors (except Ryzen 5 3400G & Ryzen 3 3200G) and AMD Ryzen 4000 G-Series desktop processors, ensuring compatibility with high-performance CPUs With a Micro-ATX form factor measuring 9.6 x 9.6 inches, the MSI B550M Pro-VDH fits into most mid-size PC cases while providing extensive connectivity and expansion options. It features one PCIe 4.0/3.0 x16 slot for high-speed GPUs and two PCIe 3.0 x1 slots for additional expansion cards. Storage options are also impressive, with two M.2 slots supporting PCIe 4.0/3.0 and four SATA 6Gb/s ports, ensuring fast data transfer and high storage capacity. The motherboard supports up to 128GB of DDR4 RAM across four slots, with speeds reaching 4400+ MHz (OC mode), making it ideal for demanding applications and gaming. For graphics output, it includes one VGA port, one HDMI 2.1 port, and one DisplayPort, supporting resolutions up to 4096x2160 @60Hz. Connectivity is seamless with Realtek 8111HN Gigabit LAN, multiple USB 3.2 Gen 1 ports, and onboard 7.1-channel HD audio with Realtek ALC892 codec for an immersive sound experience. The board also features RGB and RAINBOW LED connectors, allowing for customizable lighting setups With MSI’s premium build quality, advanced cooling solutions, and a 3-year warranty, the B550M Pro-VDH is   reliable, high-performance motherboard that delivers excellent value for PC builders.

Quick Compare

Product Details
Product MSI B550M Pro-VDH AMD AM4 DDR4 Micro-ATX Motherboard Biostar B650MT-E PRO Micro ATX AM5 Motherboard MSI PRO B650M-B DDR5 AMD Motherboard Asus PRIME B650M-F AM5 mATX Motherboard
Image MSI B550M Pro-VDH AMD AM4 DDR4 Micro-ATX Motherboard Biostar B650MT-E PRO Micro ATX AM5 Motherboard MSI PRO B650M-B DDR5 AMD Motherboard Asus PRIME B650M-F AM5 mATX Motherboard
Price 17,500৳ 14,200৳ 17,500৳ 14,300৳ 16,500৳ 13,900৳ 17,500৳ 13,900৳
Model B550M Pro-VDH B650MT-E PRO PRO B650M-B PRIME B650M-F
Brand MSI BIOSTAR MSI Asus
Availability In Stock In Stock In Stock In Stock
Rating
Based on 0 reviews.

Based on 0 reviews.

Based on 1 reviews.

Based on 0 reviews.
Summary MSI B550M Pro-VDH AMD AM4 DDR4 Micro-ATX MotherboardMSI B550M Pro-VDH AMD AM4 DDR4 Micro-ATX Motherboard is designed to deliver powerful performance and versatility, making it an excellent choice for gamers, content creators, and professionals. Built with AMD’s B550 chipset, this motherboard supports AMD Ryzen 5000 & 3000 Series desktop processors (except Ryzen 5 3400G & Ryzen 3 3200G) and AMD Ryzen 4000 G-Series desktop processors, ensuring compatibility with high-performance CPUs With a Micro-ATX form factor measuring 9.6 x 9.6 inches, the MSI B550M Pro-VDH fits into most mid-size PC cases while providing extensive connectivity and expansion options. It features one PCIe 4.0/3.0 x16 slot for high-speed GPUs and two PCIe 3.0 x1 slots for additional expansion cards. Storage options are also impressive, with two M.2 slots supporting PCIe 4.0/3.0 and four SATA 6Gb/s ports, ensuring fast data transfer and high storage capacity. The motherboard supports up to 128GB of DDR4 RAM across four slots, with speeds reaching 4400+ MHz (OC mode), making it ideal for demanding applications and gaming. For graphics output, it includes one VGA port, one HDMI 2.1 port, and one DisplayPort, supporting resolutions up to 4096x2160 @60Hz. Connectivity is seamless with Realtek 8111HN Gigabit LAN, multiple USB 3.2 Gen 1 ports, and onboard 7.1-channel HD audio with Realtek ALC892 codec for an immersive sound experience. The board also features RGB and RAINBOW LED connectors, allowing for customizable lighting setups With MSI’s premium build quality, advanced cooling solutions, and a 3-year warranty, the B550M Pro-VDH is   reliable, high-performance motherboard that delivers excellent value for PC builders... Biostar B650MT-E PRO Micro ATX AM5 MotherboardBiostar B650MT-E PRO Micro ATX AM5 Motherboard, a cutting-edge motherboard that combines high performance and advanced features to enhance your computing experience. Designed with the latest AMD B650 chipset, this motherboard is built to support the Socket AM5 and is compatible with AMD Ryzen™ 7000 and 8000 series processors. With a simple BIOS update, it also provides support for future AMD Ryzen processors, ensuring that your system remains upgradable and future-proof. The Biostar B650MT-E PRO boasts an impressive memory capacity, supporting Dual Channel DDR5 memory with speeds of up to 6000+(OC) MHz. With four DDR5 DIMM slots, this motherboard can accommodate a maximum of 192 GB of memory, allowing for smooth multitasking and seamless performance. Each DIMM slot supports non-ECC DDR5 modules with capacities ranging from 8 to 48 GB. When it comes to storage, the Biostar B650MT-E PRO offers ample options. It includes two M.2 sockets and four SATA III ports, giving you the flexibility to connect various storage devices. The M.2 sockets support both PCIe 4.0 x4 (64Gb/s) NVMe/AHCI SSDs, while the SATA III ports support AHCI and RAID 0, 1, and 10 configurations. Equipped with a Realtek RTL8125B LAN controller, this motherboard provides reliable and high-speed networking capabilities. It supports auto-negotiation for speeds of 10/100/1000/2500 Mb/s and offers half/full duplex capability. The onboard ALC897 audio codec ensures immersive and high-quality sound with its 7.1 channel support, delivering a truly Hi-Fi audio experience. The Biostar B650MT-E PRO offers a comprehensive range of connectivity options. It features two USB 3.2 Gen2 Type-C ports, one USB 3.2 Gen2 port, six USB 3.2 Gen1 ports, and six USB 2.0 ports. In terms of expansion slots, it provides one PCIe 4.0 x16 slot, two PCIe 4.0 x1 slots for AMD Ryzen processors, and one PCIe 4.0 x1 slot for the AMD B650 chipset With a compact Micro ATX form factor measuring 24.4cmx24.4cm, this motherboard is designed to fit into smaller cases without sacrificing performance. It supports Windows 10 (64-bit) and Windows 11 (64-bit), ensuring compatibility with the latest operating systems. The Biostar B650MT-E PRO comes bundled with BullGuard software, providing added security and peace of mind. Additionally, it includes two SATA cables, an I/O shield, a DVD driver, a quick guide, and WiFi antenna accessories. Backed by a 3-year warranty, you can trust in the reliability and durability of this motherboard. In conclusion, the Biostar B650MT-E PRO Micro ATX AM5 Motherboard is an excellent choice for users seeking a powerful and versatile motherboard that supports the latest AMD Ryzen processors. With its impressive memory capacity, storage options, connectivity features, and compact form factor, this motherboard delivers exceptional performance for a wide range of computing needs.FeaturesPowerful Chipset: The Biostar B650MT-E PRO is equipped with the AMD B650 chipset, ensuring optimal performance and compatibility with the latest AMD Ryzen™ 7000 and 8000 series processors. This chipset provides a solid foundation for smooth multitasking and efficient computing.Socket AM5 CPU Support: This motherboard supports the Socket AM5, allowing you to install AMD Ryzen™ 7000 and 8000 series processors. Additionally, with a BIOS update, it also provides support for future AMD Ryzen processors, ensuring that your system remains compatible and upgradable.High-Speed Memory Support: The B650MT-E PRO supports Dual Channel DDR5 memory, providing an impressive maximum capacity of up to 192 GB. It supports overclocked memory speeds of up to DDR5 6000+ (OC), enabling faster data transfer rates and improved system responsiveness.Versatile Storage Options: This motherboard offers a total of 2 x M.2 sockets and 4 x SATA III ports, providing a wide range of storage options. The M.2 sockets support both PCIe 4.0 x4 (64Gb/s) NVMe and AHCI SSDs, allowing for lightning-fast data transfer speeds. The SATA III ports also support AHCI and RAID 0, 1, and 10 configurations.Reliable Networking: With the inclusion of the Realtek RTL8125B LAN chipset, the B650MT-E PRO ensures stable and high-speed network connectivity. It supports auto-negotiation for 10/100/1000/2500 Mb/s Ethernet connections, providing flexibility for different network setups.Immersive Audio Experience: The motherboard features the ALC897 audio codec, delivering a high-definition audio experience with 7.1 channels. Whether you're gaming, watching movies, or listening to music, the Hi-Fi audio output ensures vibrant and immersive sound quality.Extensive USB Connectivity: The B650MT-E PRO offers a generous selection of USB ports, including 2 x USB 3.2 Gen2 Type-C ports, 1 x USB 3.2 Gen2 port, 6 x USB 3.2 Gen1 ports, and 6 x USB 2.0 ports. This allows for seamless connectivity of various peripherals and devices, catering to your diverse needs.Expansion and I/O Options: The motherboard provides ample expansion options with 1 x PCIe 4.0 x16 slot, 2 x PCIe 4.0 x1 slots, and 1 x PCIe 4.0 x1 slot. Additionally, the rear I/O features a range of ports, including HDMI, DP, USB, LAN, and audio ports, ensuring convenient connectivity with external devices... MSI PRO B650M-B DDR5 AMD MotherboardMSI Pro B650M-B DDR5 AMD AM5 M-ATX Motherboard is a cutting-edge motherboard designed to meet the demands of modern computing. Engineered for compatibility with the latest AMD AM5 processors, this motherboard supports DDR5 memory technology, ensuring high-speed and efficient multitasking capabilities. Its Micro-ATX form factor strikes a balance between compact size and functionality, making it an ideal choice for space-conscious users without compromising on performance. The B650M-B boasts a robust power delivery system, providing stable and reliable power to the CPU for optimal performance. Multiple expansion slots and ports allow for versatile customization, catering to diverse connectivity needs. Equipped with advanced features such as PCIe 4.0 support, users can harness the full potential of high-speed data transfer for graphics cards, storage devices, and other peripherals. MSI's renowned build quality and durability are evident in the motherboard's construction, ensuring a reliable foundation for your system. Enhanced audio and networking capabilities contribute to an immersive computing experience. Whether you're a gamer, content creator, or power user, the MSI Pro B650M-B DDR5 AMD AM5 M-ATX Motherboard provides a solid platform for building a high-performance and feature-rich system. Upgrade to the future of computing with this motherboard, where innovation and reliability converge seamlessly.Msi Pro B650m-b Motherboard Price in BDUpgrade your office computing experience with the MSI Pro B650M-B DDR5 Motherboard, tailored for optimal performance and efficiency in professional environments. Compatible with the latest AMD AM5 processors and featuring DDR5 memory support, this motherboard ensures seamless multitasking and reliable processing power for productivity tasks. With a Micro-ATX form factor, it's space-efficient for office setups. The best price list in Bangladesh makes it an attractive choice for businesses aiming to enhance their computing infrastructure without breaking the budget. Trust in MSI's renowned build quality and the cost-effectiveness offered by the best price list for a reliable and affordable office computing solution.FeaturesAMD AM5 Compatibility: Designed to support the latest AMD AM5 processors, ensuring compatibility with the newest generation of high-performance CPUs.DDR5 Memory Support: Harness the power of DDR5 memory technology for improved data transfer rates, responsiveness, and multitasking capabilities.Micro-ATX Form Factor: Strikes a balance between compact size and functionality, making it suitable for space-efficient builds without compromising on performance.Robust Power Delivery: Features a reliable power delivery system to ensure stable and efficient power supply to the CPU, promoting optimal performance.PCIe 4.0 Support: Unlock the full potential of high-speed data transfer for graphics cards, storage devices, and other PCIe 4.0-compatible peripherals.Versatile Expansion Slots and Ports: Multiple expansion slots and ports provide flexibility for customization, accommodating various connectivity needs and peripherals.MSI Build Quality: Known for durability and quality, MSI delivers a motherboard built to withstand the demands of modern computing, ensuring long-term reliability.Enhanced Audio: Enjoy an immersive audio experience with enhanced audio capabilities, providing clear and high-quality sound for gaming, entertainment, and communication.Networking Capabilities: Optimized networking features contribute to a seamless online experience, with fast and stable connections for gaming and content streaming.Innovative Design: The motherboard incorporates the latest design trends and innovations, ensuring a visually appealing and modern aesthetic for your system build... Asus PRIME B650M-F AM5 mATX MotherboardAsus PRIME B650M-F AM5 mATX Motherboard is a powerful, feature-packed option for users looking to build a high-performance PC. Built to support AMD’s Ryzen 9000, 8000, and 7000 series desktop processors, this motherboard is ideal for those who demand cutting-edge performance for gaming, content creation, and multitasking.With the AMD B650 chipset, the PRIME B650M-F offers excellent performance and features such as DDR5 memory support, up to 96GB capacity, and overclocking capabilities with AMD Extended Profiles for Overclocking (EXPO). This allows users to push their system’s memory performance to new heights, whether for gaming or demanding applications. The motherboard also supports PCIe 4.0, providing high-speed connectivity for graphics cards and other expansion cards.For high-quality audio, the PRIME B650M-F features a Realtek 7.1 Surround Sound High Definition Audio CODEC, with premium capacitors and audio shielding, ensuring clear and immersive sound. It also supports 4K video output via HDMI 2.1, making it a great choice for media enthusiasts.Storage is robust with one M.2 slot supporting PCIe 4.0 x4 mode and four SATA 6Gb/s ports, allowing you to connect multiple drives for fast data access. The motherboard also supports RAID configurations via AMD RAIDXpert2 technology, offering flexible storage options.Designed with durability and user-friendliness in mind, the motherboard includes ASUS 5X Protection III, which provides safety features like overvoltage protection and SafeSlot Core. The inclusion of ASUS EZ DIY tools like BIOS FlashBack and EZ Flash 3 ensures an easy setup, while Aura Sync RGB lighting support allows for custom lighting.With a 3-year warranty, the Asus PRIME B650M-F is a reliable, high-performance motherboard ideal for modern computing needs.FeaturesSupports AMD Ryzen 9000, 8000, & 7000 Series CPUs: Compatible with the latest AMD processors for powerful performance.DDR5 Memory Support: Up to 96GB of high-speed DDR5 memory, with overclocking support for enhanced performance.PCIe 4.0 Support: Offers fast data transfer speeds for graphics cards and expansion cards.Realtek 7.1 Surround Sound: High-definition audio with premium capacitors and audio shielding for clear sound quality.4K Output via HDMI 2.1: Enjoy smooth 4K video output for media and gaming.Multiple Storage Options: 1 x M.2 PCIe 4.0 x4 slot and 4 x SATA 6Gb/s ports for high-speed data access.ASUS 5X Protection III: Built-in safety features including overvoltage protection and SafeSlot Core for durability.Aura Sync RGB: Customizable lighting with addressable Gen 2 headers for a personalized setup.Easy Installation: ASUS EZ DIY features like BIOS FlashBack and EZ Flash 3 for simple and stress-free setup.3-Year Warranty: Ensuring long-term reliability and performance...
