MSI MAG Z790 TOMAHAWK WIFI DDR4 Intel 12th and 13th Gen ATX Motherboard
-2 %
MSI MAG Z790 TOMAHAWK WIFI DDR4 Intel 12th and 13th Gen ATX Motherboard
Discontinued
- Stock: Discontinued
- Brand: MSI
- Model: Model
Discontinued
Key Features
- ATX Form Factor
- Intel Z790 Chipset
- LGA 1700 Socket
- 4 x Dual-Channel DDR4-5333 (OC)
Contact for Bulk Quantity: 01771833944
অর্ডার করার পূর্বে কাস্টমার কেয়ার থেকে পন্যের স্টক ও ডেলিভারি সম্পর্কে জেনে নেয়ার অনুরোধ করা যাচ্ছে। প্রযুক্তি পণ্যের মূল্য অস্থিতিশীল হওয়ায় কারণে যেকোন মুহূর্তে যেকোন প্রযুক্তি পণ্যের মূল্য পরিবর্তন হতে পারে।
| General Information | |
| Display Port (s) | 1x DisplayPort 1.4 |
| M.2 Socket | 4x M.2 slots |
| Manufacturing Warranty | 3 years |
| Memory | Type: DDR4
Slots: 4 x DIMM Supported Memory 4x DDR4, Maximum Memory Capacity 128GB Max. overclocking frequency: 1DPC 1R Max speed up to 5333+ MHz 1DPC 2R Max speed up to 4800+ MHz 2DPC 1R Max speed up to 4400+ MHz 2DPC 2R Max speed up to 4000+ MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel® Extreme Memory Profile Maximum Memory: 128GB |
| PCI | 2x PCI-E x16 slot Supports x16/x4 1x PCI-E x1 slot PCI_E1 PCIe 5.0 supports up to x16 (From CPU) PCI_E2 PCIe 3.0 supports up to x1 (From the Chipset) PCI_E3 PCIe 4.0 supports up to x4 (From Chipset) |
| Special Features | LED FEATURE: 4x EZ Debug LED |
| Wireless Communication module | Intel Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (160MHz) up to 2.4Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth 5.2, FIPS, FISMA |
| Main Features | |
| Audio | 1x Front Audio (JAUD) |
| Chipset | Intel Z690 Chipset |
| Form Factor | ATX Form Factor 243.84mmx304.8mm |
| Supported CPU | Supports 12th/13th Gen Intel Core Processors, Pentium Gold, and Celeron Processors Processor socket LGA1700 |
| Graphics Specifications | |
| Graphics Memory | 1x HDMI 1x DisplayPort Support HDMITM 2.1 with HDR, maximum resolution of 4K 60Hz Support DP 1.4, the maximum resolution of 8K 60Hz |
| Connector & ports | |
| HDMI | 1x HDMI 2.1 |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 6x System Fan 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x TBT connector (JTBT, supports RTD3) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 4x USB 2.0 2x USB 3.2 Gen1 Type A 1x USB 3.2 Gen2 Type C |
| LAN Port (s) | Intel 2.5Gbps LAN |
| Supported Storage | 4x M.2 slot M.2_1 (From CPU) supports up to PCIe 4.0 x4, supports 22110/2280/2260 devices M.2_2 (From Chipset) supports up to PCIe 4.0 x4, supports 2280/2260 devices M.2_3 (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices M.2_4 (From Chipset) supports up to PCIe 4.0 x4, supports 2280/2260/2242 devices 7x SATA 6G port |
| USB (s) | 4x USB 2.0 (Front) 4x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) 4x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Rear) 1x USB 3.2 Gen2 Type C (Front) 1x USB 3.2 Gen2x2 Type C (Rear) |
MSI MAG Z790 TOMAHAWK WIFI DDR4 13th Gen ATX Motherboard
MSI's MAG Z790 TOMAHAWK WIFI DDR4 LGA 1700 ATX Motherboard provides seamless connectivity to your system. This ATX motherboard, which uses the Intel Z790 chipset and LGA 1700 socket, has four DDR4 RAM slots that allow twin-channel memory and speeds up to 5333 MHz when overclocked. Storage is abundant with seven SATA III and four M.2 connections that enable RAID 0, 1, 5, and 10. GPUs and other adaptor cards can be installed using PCIe 5.0 x16, PCIe 4.0 x16, and PCIe 3.0 x1 slots. Benefit from quick networking with a 2.5 GbE Intel LAN and Wi-Fi 6E; easily connect to wireless peripherals with Bluetooth 5.2. The Realtek ALC4080 audio codec offers 7.1 channel surround sound, and the rear ports can be used for analog or digital output. Connect connected peripherals to four USB 3.2 Gen 1 and four USB 3.2 Gen 2 Type-A ports, or to two USB 3.2 Gen 2 and two Type-C ports. DisplayPort and HDMI are used to output video. There are also Clear CMOS and Flash BIOS buttons on the back I/O panel. Front-panel USB 3.2 Gen 2 Type-C and USB 3.2 Gen 1 and 2.0 Type-A ports, RGB connections, chassis intrusion, a TPM module, and other features are supported through internal headers.
Features
- Supports 12th and 13th Gen Intel Core processors for LGA 1700 socket
- Dual-channel DDR4 memory, up to 128GB, with support for XMP overclocking profiles
- Two PCIe 5.0 x16 slots for high-speed graphics cards and one PCIe 4.0 x4 slot for NVMe SSDs
- Features WiFi 6E for fast wireless internet speeds and Bluetooth 5.2 for wireless device connectivity
- Equipped with 2.5G LAN and Gigabit LAN for fast and reliable wired internet connectivity
- Pre-installed I/O shield for easy installation and protection of ports
- Built-in Mystic Light RGB lighting system for customization of lighting effects
- Supports USB 3.2 Gen 2x2 and Thunderbolt 4 for high-speed data transfer and device charging
- Includes MSI CoreBoost and VRM Heatpipe design for stable and efficient power delivery to components.
