MSI PRO B650M-A WIFI DDR5 AMD AM5 mATX Motherboard
-22 %
MSI PRO B650M-A WIFI DDR5 AMD AM5 mATX Motherboard
- Stock: In Stock
- Brand: MSI
- Model: Model
Key Features
- Supported CPU: Ryzen 7000 Series
- Form Factor:mATX 243.84mmx243.84mm
- Graphics Output: 1x HDMI, 1x Display Port
- Chipset:AMD B650
Contact for Bulk Quantity: 01771833944
অর্ডার করার পূর্বে কাস্টমার কেয়ার থেকে পন্যের স্টক ও ডেলিভারি সম্পর্কে জেনে নেয়ার অনুরোধ করা যাচ্ছে। প্রযুক্তি পণ্যের মূল্য অস্থিতিশীল হওয়ায় কারণে যেকোন মুহূর্তে যেকোন প্রযুক্তি পণ্যের মূল্য পরিবর্তন হতে পারে।
| Main Features | |
| Audio | Audio Connectors |
| Chipset | AMD B650 |
| Form Factor | mATX 243.84mmx243.84mm |
| Supported CPU | Supports AMD Ryzen 7000 Series Desktop Processors Socket AM5 |
| General Information | |
| Type | DDR5 |
| Display Port (s) | 1x DisplayPort |
| Manufacturing Warranty | 3 Years |
| PCI | 2x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 PCIe 4.0 supports up to x16 (From CPU) PCI_E2 PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 PCIe 4.0 supports up to x4 (From Chipset) |
| RAID | Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices Supports RAID 0 and RAID 1 for M.2 NVMe storage devices |
| Slots | 4 DIMMs |
| Special Features | 4x EZ Debug LED |
| Wireless Communication module | AMD Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth 5.2 |
| Graphics Specifications | |
| Graphics Memory | 1x HDMI 1x DisplayPort Support HDMI 2.1, maximum resolution of 4K 60Hz Supports DP1.4, maximum resolution of 4K 60Hz |
| Memory Specifications | |
| Maximum Memory | 128GB |
| Supported Memory | Memory Support DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz Max. overclocking frequency: • 1DPC 1R Max speed up to 6400+ MHz • 1DPC 2R Max speed up to 5800+ MHz • 2DPC 1R Max speed up to 6000+ MHz • 2DPC 2R Max speed up to 4000+ MHz Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports AMD EXPO |
| Connector & ports | |
| HDMI | 1x HDMI |
| Internal I/O Ports | 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 3x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x Tuning Controller connector(JDASH) 2x Addressable V2 RGB LED connector (JARGB_V2) 2x RGB LED connector(JRGB) 4x USB 2.0 2x USB 3.2 Gen1 Type A 1x USB 3.2 Gen2 Type C |
| LAN Port (s) | Realtek 8125BG 2.5G LAN |
| Supported Storage | 2x M.2 slot M.2_1 (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_2 (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 4x SATA 6G port |
| USB (s) | 4x USB 2.0 (Front) 4x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) 4x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Front) |
MSI PRO B650M-A WIFI AMD mATX Motherboard
The MSI PRO B650M-A WIFI Motherboard supports AMD's Ryzen 7000-series processors with up to 16 Zen 4 cores as well as dual-channel DDR5 memory, with a Maximum Memory Capacity of up to 128GB and a bus speed of up to 6400+(OC) MHz. It features a Core Boost technology that combines MSI's premium layout and optimized power design which allows for faster and undistorted current delivery to the CPU at pin-point precision. Not only supports multi-core CPUs, but also creates the perfect conditions for your CPU overclocking. It has an extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and a Double-sided M.2 Shield Frozr built for a high-performance system and a non-stop gaming experience. The motherboard is made of a 6-layer PCB made of 2oz thickened copper and server-grade level material. It can deliver a lightning-fast game experience with PCIe 4.0 slots, Lightning Gen 4 x4 M.2 with M.2 Shield Frozr design keeps M.2 SSDs safe while preventing throttling, making them run faster. The rear I/O panel now offers easy ways of directly entering the safe boot, a one-click toggle for all RGB lights, and directly activating Turbo mode. The MSI PRO B650M-A WIFI offers Built-in USB 3.2 Gen 2x2 port, offers 20Gbps transmission speed, 4X faster than USB 3.2 Gen 1. The MAG B650 series motherboards offer a wide variety of options to connect and boost your USB devices, offering never before seen USB speeds up to 20Gb/s when connecting the Rear USB Type-C.Quick Compare
| Product Details | ||||
| Product | MSI PRO B650M-A WIFI DDR5 AMD AM5 mATX Motherboard | Gigabyte B550 GAMING X V2 Motherboard | Gigabyte B850M D3HP AMD Socket AM5 Motherboard | ASRock B650M PG Lightning WiFi AM5 Micro ATX Motherboard |
| Image | |
|
|
|
| Price | |
|
|
|
| Model | Model | B550-V2 | B850M D3HP | B650M PG Lightning |
| Brand | MSI | Gigabyte | Gigabyte | ASRock |
| Availability | In Stock | In Stock | In Stock | In Stock |
| Rating | Based on 0 reviews. |
Based on 0 reviews. |
Based on 0 reviews. |
Based on 0 reviews. |
| Summary | MSI PRO B650M-A WIFI AMD mATX Motherboard The MSI PRO B650M-A WIFI Motherboard supports AMD's Ryzen 7000-series processors with up to 16 Zen 4 cores as well as dual-channel DDR5 memory, with a Maximum Memory Capacity of up to 128GB and a bus speed of up to 6400+(OC) MHz. It features a Core Boost technology that combines MSI's premium layout and optimized power design which allows for faster and undistorted current delivery to the CPU at pin-point precision. Not only supports multi-core CPUs, but also creates the perfect conditions for your CPU overclocking. It has an extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and a Double-sided M.2 Shield Frozr built for a high-performance system and a non-stop gaming experience. The motherboard is made of a 6-layer PCB made of 2oz thickened copper and server-grade level material. It can deliver a lightning-fast game experience with PCIe 4.0 slots, Lightning Gen 4 x4 M.2 with M.2 Shield Frozr design keeps M.2 SSDs safe while preventing throttling, making them run faster. The rear I/O panel now offers easy ways of directly entering the safe boot, a one-click toggle for all RGB lights, and directly activating Turbo mode. The MSI PRO B650M-A WIFI offers Built-in USB 3.2 Gen 2x2 port, offers 20Gbps transmission speed, 4X faster than USB 3.2 Gen 1. The MAG B650 series motherboards offer a wide variety of options to connect and boost your USB devices, offering never before seen USB speeds up to 20Gb/s when connecting the Rear USB Type-C... | Gigabyte B550 GAMING X V2 Motherboard Gigabyte B550 GAMING X V2 Motherboards maximize your PC's potential with AMD StoreMI technology. StoreMI accelerates traditional storage devices to reduce boot times and enhance the overall user experience. This easy-to-use utility combines the speed of SSDs with the high capacity of HDDs into a single drive, enhances the read/write speeds of the device to match that of SSDs, bolsters data performance for incredible value, and transforms the everyday PC to a performance-driven system. PERFORMANCE B550 motherboard use a 10+3 phases pure digital PWM + Low RDS(on) MOSFETs design to support the 3rd Gen AMD Ryzen™ CPUs by offering incredible precision in delivering power to the motherboard's most power-hungry and energy-sensitive components as well as delivering enhanced system performance and ultimate hardware scalability. CONNECTIVITY With NVMe PCIe 4.0/ 3.0 x4 and PCIe 3.0 x4 M.2 connectors onboard, GIGABYTE Motherboards bring users to experience NVMe mode or SATA mode connectivity for M.2 SSD devices. Delivering up to 64 Gb/s data transfer speed, the dual M.2 connectors design provides an ideal storage solution while also supporting in RAID modes. Exclusive Realtek 8118 Gaming LAN Realtek 8118 LAN is a high performance and friendly network chip for gaming players with automatic bandwidth allocation to ensure the highest network priority of the game or application. It can provide users the most comprehensive features and the fastest and smoothest Internet experience. HDMI 2.1 for 4K / 60P / 21:9 / HDCP 2.3 Support HDMI 2.1, which is backwards compatible with HDMI 2.0/ 1.4 and offering 48 Gb/s of bandwidth – twice times more than previous generation. This unlocks the potential for users to transfer multiple video streams, as well as a native cinematic 21:9 ratio (which most movies are shot in), Full HDR and HDCP 2.3 support, to offer the best visual experience for viewers. LIGHTING With B550 Motherboards, RGB Fusion 2.0 is even better with Addressable LEDs. RGB Fusion 2.0 offers users the option to control onboard RGB and external RGB / Addressable LED light strips for their PC build. Already feature filled with colors and patterns, RGB Fusion 2.0 are now upgraded to improve the Addressable LED support. With external Addressable LED strips, where each LED is digitally addressable that users can experience even more patterns, styles, and illuminations. With B550 Motherboards support the external 5V Addressable LED lighting strips and up to 300 LED lights. RGB Fusion 2.0 with Addressable LEDs comes with new patterns and various speed settings with more to come. With an integrated intuitive user interface, the RGB Fusion 2.0 provides you a better solution for customizing the lighting effects across all supported devices. From motherboards, graphics cards to the peripheral products, you can personalize your gaming rig with your own style and show off your build by sharing the profiles. In addition, the new gaming mode makes the lighting effects interactive with selected games to bring you the most immersive gaming experience. AUDIO GIGABYTE motherboards use high-end audio capacitors. These high quality capacitors help deliver high resolution and high fidelity audio to provide the most realistic sound effects for gamers. GIGABYTE motherboards feature an audio noise guard that essentially separates the board’s sensitive analog audio components from potential noise pollution at the PCB level. ULTRA DURABLE With GIGABYTE Q-Flash Plus, you don’t need to install the CPU, memory and graphics card nor enter the BIOS menu to flash the BIOS. Just download and save a new BIOS file (rename to gigabyte.bin) on the USB flash drive, then press the dedicated Q-Flash Plus button and you’re good to go! [ninja_tables id="47268"].. | Gigabyte B850M D3HP AMD Socket AM5 MotherboardGigabyte B850M D3HP AMD Socket AM5 Motherboard is a powerful and feature-packed Micro ATX motherboard designed for high-performance computing. Built with the AMD B850 chipset, it supports AMD Ryzen 9000, 8000, and 7000 series processors, making it a versatile choice for gamers, content creators, and professionals. This motherboard supports DDR5 memory, with speeds up to 8200 MT/s (OC) and a maximum capacity of 256GB across four DIMM slots. With dual-channel architecture and AMD EXPO/XMP support, users can achieve optimized memory performance for demanding applications. For storage, the B850M D3HP offers two M.2 slots with PCIe 5.0/4.0 support, ensuring ultra-fast data transfer speeds for NVMe SSDs. Additionally, four SATA 6Gb/s ports enable RAID configurations, providing both speed and redundancy for data protection. The motherboard features integrated AMD Radeon Graphics, delivering high-quality visuals through one HDMI 2.1 port (4K@60Hz) and two DisplayPorts (4K@144Hz). This makes it ideal for multi-monitor setups and high-resolution gaming. Networking is powered by a Realtek GbE LAN chip, ensuring stable and fast internet connectivity. The board also includes multiple USB ports, including USB 3.2 Gen 1 and USB Type-C, for high-speed peripheral connectivity. Designed with durability in mind, the Gigabyte B850M D3HP comes with advanced cooling solutions, RGB lighting support, and 3-year warranty coverage. Whether you're building a gaming PC or a workstation, this motherboard offers the reliability, speed, and expandability required for modern computing needs... | ASRock B650M PG Lightning WiFi AM5 Micro ATX MotherboardThe ASRock B650M PG Lightning WiFi AM5 Micro ATX Motherboard is a high-performance motherboard designed to support AMD's latest Ryzen 9000, 8000, and 7000 series processors, making it an ideal choice for gamers and PC enthusiasts. Built on the AMD B650 chipset, this motherboard offers robust performance, modern features, and excellent connectivity, all in a compact micro ATX form factor. One of its standout features is support for PCIe Gen5 on the M.2 slot, delivering ultra-fast speeds for storage devices. The board includes multiple M.2 sockets: one Blazing M.2 for PCIe Gen5 x4 speeds, and two additional M.2 sockets supporting PCIe Gen4. This allows users to take full advantage of next-gen SSDs for lightning-fast data transfers and seamless gaming experiences. Additionally, it offers four SATA3 ports for further storage expansion. For memory, the B650M PG Lightning supports DDR5 technology, allowing up to 256GB of ECC and non-ECC memory, with speeds reaching 7200MHz+ through overclocking. This makes it highly suitable for intensive multitasking, gaming, and content creation. Connectivity is another strength of this motherboard. It comes equipped with Wi-Fi 6E for faster wireless connections, Bluetooth 5.2, and 2.5G LAN with intelligent bandwidth control, making it perfect for both wired and wireless networking needs. The rear I/O panel also offers a variety of ports, including USB 3.2 Gen2 Type-C and Type-A ports, as well as HDMI and DisplayPort outputs for 4K displays. Designed for durability and stability, the board features a 6+2+1 power phase design with Dr.MOS technology, ensuring reliable performance even under heavy loads. It also includes a BIOS Flashback button and supports easy updates via the ASRock Auto Driver Installer. The 3-year warranty ensures peace of mind for users looking for long-term reliability.ASRock B650M PG Lightning WiFi AM5 Micro ATX Motherboard FeaturesSupports Latest AMD Ryzen Processors: Compatible with AMD Socket AM5 Ryzen 9000, 8000, and 7000 series processors, offering excellent performance for gaming, productivity, and content creation.DDR5 Memory Support: Features dual-channel DDR5 memory technology, supporting up to 256GB and offering speeds of up to 7200+ MHz (overclocked) for optimal performance and multitasking.PCIe Gen5 and Gen4 Slots: Includes a Blazing M.2 slot (PCIe Gen5 x4) and two Hyper M.2 slots (PCIe Gen4), enabling lightning-fast data transfer speeds for next-gen SSDs.Integrated Wi-Fi 6E and Bluetooth 5.2: Provides cutting-edge wireless connectivity with the latest Wi-Fi 6E module, supporting dual-band 2x2 and the extended 6GHz band. Bluetooth 5.2 enables fast and reliable device connections.High-Quality Audio: 7.1 channel HD audio, powered by the Realtek ALC897 codec, and enhanced by Nahimic Audio technology, offering immersive sound experiences.Comprehensive I/O Ports: Equipped with multiple USB 3.2 Gen2 and Gen1 ports, HDMI 2.1 and DisplayPort 1.4 for 4K display support, and 2.5 Gigabit LAN with intelligent bandwidth control for superior connectivity.Rock-Solid Durability: Built with a 6+2+1 power phase design and 50A Dr.MOS for stable power delivery, ensuring reliability during heavy use.EZ Update and BIOS Flashback: Easy firmware updates through the ASRock Auto Driver Installer and BIOS Flashback button, simplifying maintenance and optimization.Customizable RGB Lighting: Supports ASRock Polychrome SYNC with multiple LED headers for personalized lighting effects.3-Year Warranty: Backed by a 3-year manufacturer’s warranty for long-term reliability... |
|
|
|
|
|
|
