ASRock X870 RIPTIDE WIFI AM5 ATX Motherboard
- Stock: In Stock
- Brand: ASRock
- Model: X870 RIPTIDE WIFI
Key Features
- Supported CPU: Ryzen 9000, 8000, & 7000 Series Processors for Socket AM5
- Supported RAM: 4x DDR5, Up to 8000+(OC), Max 256GB
- Graphics Output: 1x HDMI 2.1, 2 x USB4, support HDCP 2.3 and max
- Features: 2.5 Gigabit LAN, 802.11be 2x2 Wi-Fi 7 Module, Bluetooth 5.4
| General Information | |
| Type | Dual Channel DDR5 Memory Technology |
| Audio | - 7.1 CH HD Audio with Content Protection (Realtek ALC4082 Audio Codec) - Individual PCB Layers for R/L Audio Channel - Direct Drive Technology on Front headphone port (Supports up to 600 Ohm headsets) - Nahimic Audio |
| Graphics | Integrated AMD RDNA graphics (Actual support may vary by CPU) - 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz - 2 x USB4, support HDCP 2.3 and max. resolution up to 8K 30Hz |
| M.2 Socket | CPU: - 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode* Chipset: - 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2230/2260/2280 PCIe Gen4x4 (64 Gb/s) mode* - 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode* ASMedia ASM1061: - 4 x SATA3 6.0 Gb/s Connectors |
| PCI | CPU: - 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode* - 1 x PCIe 4.0 x16 Slot (PCIE2), supports x4 mode* Chipset: - 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module - Supports AMD CrossFire™ - 15μ Gold Contact in VGA PCIe Slot (PCIE1) |
| RAID | Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices* |
| Slots | 4 x DDR5 DIMM Slots |
| Wireless Communication module | Wireless LAN - 802.11be 2x2 Wi-Fi 7 Module - Supports IEEE 802.11a/b/g/n/ac/ax/axe/be - Supports 2.4GHz/5GHz/6GHz* frequency band - Supports 160MHz channel bandwidth with 6GHz* frequency band - 1 antenna to support 2 (Transmit) x 2 (Receive) diversity technology - Supports Bluetooth 5.4 - Supports MU-MIMO |
| Main Features | |
| Chipset | AMD X870 |
| Form Factor | ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm - 8 Layer PCB |
| Supported CPU | Supports AMD Socket AM5 Ryzen 9000, 8000 and 7000 Series Processors |
| Memory Specifications | |
| Maximum Memory | 256GB |
| Supported Memory | Supports DDR5 ECC/non-ECC, un-buffered memory up to 8000+(OC)* - Max. capacity of system memory: 256GB - Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules |
| Connector & ports | |
| Internal I/O Ports | 1 x Thermistor Cable Header - 1 x Power LED and Speaker Header - 1 x RGB LED Header* - 3 x Addressable LED Headers** - 2 x CPU Fan Connectors (4-pin) (Smart Fan Speed Control)*** - 3 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)*** - 1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control)*** - 1 x 24 pin ATX Power Connector (Hi-Density Power Connector) - 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector) - 1 x Front Panel Audio Connector - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) - 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) - 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) |
| LAN Port (s) | 2.5 Gigabit LAN 10/100/1000/2500 Mb/s - Killer E3100G - Supports Killer LAN Software |
| USB (s) | CPU: - 2 x USB4 Type-C (Rear) - 1 x USB 3.2 Gen2 Type-A (Rear (USB32_3)) - 1 x USB 3.2 Gen1 Type-A (Rear (USB32_1)) Chipset: - 1 x USB 3.2 Gen2x2 Type-C (Front) - 1 x USB 3.2 Gen2 Type-A (Rear (USB32_4)) - 6 x USB 3.2 Gen1 Type-A (2 Rear (USB32_2 and USB32_5), 4 Front) - 8 x USB 2.0 (4 Rear, 4 Front) |
| Warranty Information | |
| Warranty | 3 Years |
ASRock X870 RIPTIDE WIFI AM5 ATX Motherboard
Processor & Memory Support
The board supports AMD Socket AM5 processors, offering excellent multi-core performance across various workloads. It features dual-channel DDR5 memory technology with four DIMM slots, supporting up to 256GB of high-speed RAM. With support for ECC/non-ECC modules, EXPO, and XMP profiles, users can achieve memory speeds of 8000+ MHz (OC) for smooth performance in gaming and productivity.
Expansion & Storage Performance
Designed for modern GPUs and ultra-fast storage, the X870 Riptide WiFi includes 1 PCIe 5.0 x16 slot for next-gen graphics cards and 1 PCIe 4.0 x16 slot for additional expansion. Storage options include one PCIe Gen5x4 M.2 slot for extreme SSD speeds and two PCIe Gen4x4 M.2 slots, ensuring rapid data access and minimal loading times. Additionally, four SATA3 ports support traditional drives, allowing flexibility for large-capacity storage solutions.
Connectivity Features
The motherboard excels in connectivity with a wide selection of rear and front-panel ports. It includes two USB4 Type-C ports supporting up to 40Gbps bandwidth and 8K display output, along with multiple USB 3.2 Gen2, Gen1, and USB 2.0 ports. For display, the HDMI 2.1 port supports 4K at 120Hz, ideal for high-refresh monitors and media setups.
Networking & Wireless Technology
For seamless online gaming and streaming, the board features Killer 2.5G LAN, delivering low latency and optimized network performance. The built-in Wi-Fi 7 (802.11be) module ensures ultra-fast wireless speeds, stable connections, and improved throughput across 2.4GHz, 5GHz, and 6GHz frequency bands. Bluetooth 5.4 provides enhanced connectivity for peripherals.
Audio & Cooling Enhancements
The Realtek ALC4082 codec enhances audio clarity with 7.1-channel HD sound, dedicated PCB layers, and support for 600-ohm headphones. Cooling is well managed through multiple smart fan connectors, an AIO pump header, and optimized heatsinks, ensuring stable performance even during heavy workloads.
Special Features
- BIOS Flashback Button for easy updates
- ASRock Lightning Gaming Ports for optimized peripherals
- High-density power connectors & durable black caps
- Flexible integrated I/O shield
- Buy Now – ASRock X870 Riptide WiFi from Ultra Technology
Get the latest AM5 performance and future-ready features with the ASRock X870 Riptide WiFi, available now at Ultra Technology.
Buy Now – ASRock X870 Riptide WiFi from Ultra Technology
Experience next-generation performance and reliability with the ASRock X870 Riptide WiFi, now available at Ultra Technology.
