ASUS ROG CROSSHAIR X670E HERO AM5 ATX Gaming Motherboard
Discontinued
- Stock: Discontinued
- Brand: Asus
- Model: ROG CROSSHAIR X670E HERO
Discontinued
Key Features
- Socket: AMD Socket AM5
- Memory: 4 x DIMM, Max. 192GB, DDR5
- Storage Supports: 5 x M.2 slots and 6 x SATA 6Gb/s Ports
- Features: PCIe Gen 5-ready, AI Cooling II, WiFi 6E, Polymo Lighting, Dual USB4 Type-C Port
| General Information | |
| Chipset Manufacturer | AMD X670 |
| Accessories | Cables 1 x ARGB RGB extension cable 1 x RGB extension cable 4 x SATA 6Gb/s cables PCIe 5.0 M.2 Card with Heatsink 1 x PCIe 5.0 M.2 Card with heatsink 1 x M.2 screw package for PCIe 5.0 M.2 Card Additional Cooling Kit 1 x Thermal pad for M.2 Miscellaneous 1 x ASUS Wi-Fi moving antennas 3 x Rubber Packages for M.2 backplate 1 x Q-connector 1 x M.2 Q-Latch package 3 x M.2 Q-Latch packages for M.2 backplate 1 x ROG Graphics card holder 1 x ROG key chain 1 x ROG stickers 1 x ROG thank you card Installation Media 1 x USB drive with utilities and drivers Documentation 1 x User guide |
| Audio Feature | ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082 - Impedance sense for front and rear headphone outputs - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking - High quality 120 dB SNR stereo playback output and 113 dB SNR recording input - Supports up to 32-Bit/384 kHz playback" Audio Features - SupremeFX Shielding Technology - ESS ES9218 QUAD DAC - Gold-plated audio jacks - Rear optical S/PDIF out port - Premium audio capacitors - Audio cover |
| Back Panel I/O Ports | 2 x USB4 ports with Intel JHL8540 USB4 controller (2 x USB Type-C) 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C) 9 x USB 3.2 Gen 2 ports(8 x Type-A + 1 x Type-C) 1 x HDMI port 1 x Wi-Fi Module 1 x Intel 2.5Gb Ethernet 5 x Gold-plated audio jacks* 1 x Optical S/PDIF out port 1 x BIOS FlashBack button 1 x Clear CMOS button *The rear panel Lime (Line out) port does not support spatial audio. If you wish to use spatial audio make sure to connect your audio output device to the audio jack on the front panel of your chassis. |
| Bios Information | 256Mb Flash ROM, UEFI AMI BIOS |
| CPU | AM5 Socket for AMD Ryzen Desktop Processors* * Refer to www.asus.com for CPU support list. |
| Ethernet | 1 x Intel 2.5Gb Ethernet ASUS LANGuard |
| Form Factor (Inch) | ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
| I/O Ports | Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 4 x 4-pin Chassis Fan headers 1 x W_PUMP+ header 1 x 2-pin Water In header 1 x 2-pin Water Out header 1 x 3-pin Water Flow header Power related 1 x 24-pin Main Power connector 2 x 8-pin +12V Power connector 1 x 6-pinPCIe Power connector Storage related 4 x M.2 slots (Key M) 6 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 2x2 connector (supports USB Type-C) 2 x USB 3.2 Gen 1 headers support additional 4 USB 3.2 Gen 1 ports 3 x USB 2.0 headers support additional 6USB 2.0 ports Miscellaneous 3 x Addressable Gen 2 headers 1 x Alteration Mode Switch 1 x Aura RGB header 1 x FlexKey button 1 x Front Panel Audio header (AAFP) 1 x ReTry button 1 x Start button 1 x 10-1 pin System Panel header 1 x Thermal Sensor header |
| Manageability | WOL by PME, PXE |
| Memory | 4 x DIMM, Max. 192GB, DDR5 8000+(OC)/7800(OC)/7600(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/ 5800(OC)/5600(OC)/5400(OC)/5200/5000/4800, ECC and Non-ECC, Un-buffered Memory* Dual Channel Memory Architecture Supports AMD Extended Profiles for Overclocking (EXPO) OptiMem II * Supported memory types, data rate(Speed), and number of DRAM module vary depending on the CPU and memory configuration, for more information refer to www.asus.com for memory support list. * Non-ECC, Un-buffered DDR5 Memory supports On-Die ECC function |
| Operating System | Windows 11 64-bit, Windows 10 64-bit |
| Software Features | ROG Exclusive Software - GameFirst VI - ROG CPU-Z - Sonic Studio III + Sonic Studio Virtual Mixer + Sonic Suite Companion - Sonic Radar III - DTS Sound Unbound - BullGuard or equivalent internet security (1-year full version) ASUS Exclusive Software Armoury Crate - AIDA64 Extreme (1 year full version) - Aura Creator - Aura Sync - Fan Xpert 4 with AI Cooling II - Power Saving - Polymo Lighting - Two-Way AI Noise Cancellation AI Suite 3 TPU DIGI+ Power Control Turbo app PC Cleaner MyAsus WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode |
| Special Features | Extreme OC Kit - FlexKey button - ReTry button - Start button Extreme Engine Digi+ - 10K Black Metallic Capacitors - MicroFine Alloy Choke ASUS Q-Design - M.2 Q-Latch - PCIe Slot Q-Release - Q-Code - Q-Connector - Q-DIMM - Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - Q-Slot ASUS Thermal Solution - M.2 heatsink backplate - M.2 heatsink - VRM heatsink design ASUS EZ DIY - BIOS FlashBack button - Clear CMOS button - ProCool II - Pre-mounted I/O shield - SafeSlot - SafeDIMM Aura Sync - Aura RGB header - Addressable Gen 2 headers Front Panel USB 3.2 Gen 2x2 with Quick Charge 4+ Support - Support: up to 60W charging* - Output: 5/9/15/20V max. 3A, PPS:3.3–21V max. 3A - Compatible with QC 4.0/3.0/2.0, PD3.0 and PPS * To support 60W, please install the power cable to 6-pin PCIe power connector or can only support 27W |
| Storage | Total supports 5 x M.2 slots and 6 x SATA 6Gb/s ports* AMD Ryzen 8000 / 7000 Series Desktop Processors M.2_1 slot (Key M), type 2242/2260/2280 - AMD Ryzen 7000 Series Desktop Processors support PCIe 5.0 x4 mode - AMD Ryzen 8000 Series Desktop Processors support PCIe 4.0 x4 mode M.2_2 slot (Key M), type 2242/2260/2280 - Only AMD Ryzen 7000 Series Desktop Processors support PCIe 5.0 x4 mode - AMD Ryzen 8000 Series Desktop Processors support PCIe 4.0 x2 mode PCIe 5.0 M.2 slot (Key M) via PCIe 5.0 M.2 card, type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode) - Only AMD Ryzen 7000 Series Desktop Processors support PCIe 5.0 x4 mode - AMD Ryzen 8000 Series Desktop Processors support PCIe 4.0 x4 mode AMD X670 Chipset M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 ) M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 ) 6 x SATA 6Gb/s ports *AMD RAID Xpert2 Technology supports both NVMe RAID 0/1/10 and SATA RAID 0/1/10. **Performance may vary depending on the SSD's firmware version and the system hardware & system configuration, for more information refer to www.asus.com for device support list. |
| Wireless & Bluetooth | Wi-Fi 6E 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) Supports 2.4/5/6GHz frequency band* Bluetooth v5.3** * WiFi 6E 6GHz regulatory may vary between countries, and function will be ready in Windows 11 or later. ** The Bluetooth version may vary, please refer to the Wi-Fi module manufacturer's website for the latest specifications. |
| Graphics Card | 1 x HDMI port* 2 xUSB4 ports support USB Type-C display outputs** *Supports 4K@60Hz as specified in HDMI 2.1. **VGA resolution support depends on processors' or graphic cards' resolution. |
| Physical Specification | |
| Expansion Slots | AMD Ryzen 7000 Series Desktop Processors* 2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 mode(s)* * When the PCIe 5.0 M.2 card is installed on the PCIEX16_2 slot, PCIEX16_1 will run x8 only. AMD Ryzen 8700/8600 Series Desktop Processors 2 x PCIe 4.0 x16 slots (only supports PCIEx16_1 & total bandwidth for x8, PCIEx16_2 will be disabled) AMD Ryzen 8500/8300 Series Desktop Processors 2 x PCIe 4.0 x16 slots (only supports PCIEx16_1 & total bandwidth for x4, PCIEx16_2 will be disabled) AMD X670 Chipset 1 x PCIe 4.0 x1 slots |
| Warranty Information | |
| Warranty | 3 Years Replacement Warranty *(Terms and Conditions Applied) |
ASUS ROG CROSSHAIR X670E HERO AM5 ATX Gaming Motherboard
ASUS ROG CROSSHAIR X670E HERO AM5 ATX Gaming Motherboard is a powerhouse designed to deliver exceptional performance and versatility for gaming enthusiasts and PC builders. Featuring the latest AM5 socket for AMD Ryzen Desktop Processors, this motherboard ensures compatibility with a wide range of CPUs, providing users with the flexibility to choose the perfect processor for their needs. At the heart of the X670E HERO lies the AMD X670 chipset, offering robust features and support for high-speed DDR5 memory. With four DIMM slots supporting a maximum capacity of 192GB, users can harness the power of DDR5 memory with speeds up to 8000MHz (OC), enabling smooth multitasking, gaming, and content creation. The motherboard boasts an array of expansion slots, including two PCIe 5.0 x16 slots and a PCIe 4.0 x1 slot, providing ample room for high-performance graphics cards, storage devices, and expansion cards. Whether gaming, rendering, or streaming, users can customize their system to suit their specific requirements. Storage options abound with support for up to five M.2 slots and six SATA 6Gb/s ports, allowing for lightning-fast NVMe SSDs and high-capacity HDDs or SATA SSDs. The inclusion of AMD RAID Xpert2 Technology enhances data management and protection, ensuring reliable storage performance. Networking is top-notch with Intel 2.5Gb Ethernet and Wi-Fi 6E capability, delivering lightning-fast connectivity for online gaming, streaming, and file transfers. Bluetooth v5.3 support further enhances connectivity options, ensuring seamless integration with a wide range of devices. The motherboard's extensive internal I/O ports provide flexibility for system customization, while the rear and front USB ports offer convenient connectivity for peripherals and accessories. The inclusion of ASUS-exclusive technologies like SupremeFX audio, Extreme Engine Digi+, and Aura Sync RGB lighting allows users to enhance their gaming experience with immersive audio and customizable lighting effects. With a host of special features including Extreme OC Kit, ASUS Q-Design, and Aura Sync, the X670E HERO offers unparalleled performance, reliability, and customization options for gamers and enthusiasts alike. Backed by a 3-year warranty, this motherboard is a solid choice for building a high-end gaming rig that can tackle any task with ease.
ASUS ROG CROSSHAIR X670E HERO AM5 ATX Gaming Motherboard Features
- AM5 Socket Compatibility: Designed for AMD Ryzen Desktop Processors, the AM5 socket ensures compatibility with the latest AMD CPUs, offering exceptional performance for gaming, content creation, and more.
- Chipset and Memory Support: Powered by the AMD X670 chipset, this motherboard supports up to 192GB of DDR5 memory across 4 DIMM slots. It features OptiMem II technology and supports AMD Extended Profiles for Overclocking (EXPO) to maximize memory performance and stability.
- Graphics Outputs: Equipped with an HDMI port and two USB4 ports that support USB Type-C display outputs, the motherboard delivers high-resolution visuals, supporting 4K@60Hz output as specified in HDMI 2.1.
- Expansion Slots: With support for AMD Ryzen 7000 Series Desktop Processors, it features two PCIe 5.0 x16 slots (with support for x16 or x8/x8 mode(s)) for high-performance graphics cards and other expansion cards. Additional PCIe slots cater to various CPU models for enhanced compatibility.
- Storage Options: Offering a plethora of storage connectivity, the motherboard supports up to 5 M.2 slots and 6 SATA 6Gb/s ports. Users can leverage PCIe 5.0 and PCIe 4.0 M.2 slots for ultra-fast NVMe SSDs, while SATA ports accommodate traditional HDDs and SSDs. AMD RAID Xpert2 Technology enhances data protection and performance.
- Networking: Featuring Intel 2.5Gb Ethernet and Wi-Fi 6E capability, users can enjoy high-speed and reliable connectivity for online gaming, streaming, and file transfers. Bluetooth v5.3 support further enhances connectivity options.
- Internal I/O Ports: The motherboard provides an array of internal headers for fan and cooling, power, storage, and USB connectivity, enabling users to customize their system configuration according to their needs.
- Back Panel I/O Ports: The rear panel offers extensive USB connectivity, including USB4 ports, USB 3.2 Gen 2 ports, and USB 3.2 Gen 2x2 ports, along with HDMI output, Ethernet port, audio jacks, and BIOS FlashBack and Clear CMOS buttons for easy troubleshooting and maintenance.
- Special Features: ASUS incorporates various technologies and design elements to enhance overclocking capabilities, power delivery, thermal management, and ease of use. Notable features include Extreme OC Kit, Extreme Engine Digi+, ASUS Q-Design, ASUS Thermal Solution, ASUS EZ DIY, and Aura Sync for customizable RGB lighting.
- Software Features: ASUS provides a suite of exclusive software tools to optimize system performance, customize lighting effects, manage fan speeds, and enhance audio experiences, among other functionalities, ensuring a seamless user experience.
- Accessories: The motherboard comes bundled with essential accessories, including cables, cooling kits, PCIe 5.0 M.2 Card with Heatsink, Wi-Fi antennas, and documentation, simplifying installation and setup for users.
Overall, the ASUS ROG CROSSHAIR X670E HERO AM5 ATX Gaming Motherboard offers a comprehensive set of features, robust performance, and extensive customization options, making it an ideal choice for enthusiasts and gamers seeking a high-end platform for their builds.
