MSI PRO Z890-S WIFI LGA 1851 ATX Motherboard
Discontinued
- Stock: Discontinued
- Brand: MSI
- Model: PRO Z890-S WIFI
Discontinued
Key Features
- Supported CPU: Intel Core Ultra Processors (Series 2), LGA 1851
- Form Factor: ATX (243.84mm x 304.8mm)
- Memory Max.: 256GB
- Ram Type: 4x DDR5, Dual Channel 8800+ MT/s (OC), Max 256GB
| Main Features | |
| Audio | Realtek ALC897 Codec 7.1-Channel High Definition Audio |
| Chipset | INTEL Z890 |
| Form Factor | ATX 243.84mmx304.8mm |
| Supported CPU | Supports Intel Core Ultra Processors (Series 2) LGA 1851 |
| Graphics Specifications | |
| Graphics | 1x HDMI Support HDMI 2.1, maximum resolution of 4K 60Hz* 1x DisplayPort Support DisplayPort 1.4, maximum resolution of 4K 60Hz* 1x Type-C DisplayPort Thunderbolt 4 port, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz* |
| Memory Specifications | |
| Maximum Memory | 256GB |
| Slots | 4x UDIMM |
| Supported Memory | Memory Support 8800 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s Max. overclocking frequency: • 1DPC 1R Max speed up to 8800+ MT/s • 1DPC 2R Max speed up to 7200+ MT/s • 2DPC 1R Max speed up to 6400+ MT/s • 2DPC 2R Max speed up to 5600+ MT/s Supports Intel POR Speed and JEDEC Speed Supports Memory Overclocking and Intel® XMP 3.0 Supports Dual-Controller Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM |
| Type | DDR5 |
| Connector & ports | |
| Audio | 1x Front Audio (JAUD) |
| Display Port (s) | 1x DisplayPort 1x Type-C DisplayPort Thunderbolt 4 port, supporting DisplayPort 2.1 with UHBR20 over USB Type-C, with a maximum resolution of 4K@120Hz / 8K@60Hz |
| HDMI | 1x HDMI 2.1 |
| Internal I/O Ports | 1x Thunderbolt5 card connector(JTBT5, support RTD3) 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 4x System Fan 1x EZ Conn-header (JAF_1) 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 20Gbps Type C ports |
| LAN Port (s) | Realtek 8125D 2.5Gbps LAN |
| RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe storage devices |
| Supported Storage | 3x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices 4x SATA 6G |
| USB (s) | 4x USB 2.0 (Front) 6x USB 5Gbps Type A (Rear) 2x USB 5Gbps Type A (Front) 1x USB 20Gbps Type C (Rear) 1x USB 20Gbps Type C (Front) |
| Wireless Communication module | Intel Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be Supports Bluetooth 5.4**, MLO, 4KQAM |
| Expansion Slots | |
| M.2 Socket | 3x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260/2242 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices |
| PCI | 4x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) PCI_E4 Gen PCIe 4.0 supports up to x4 (From CPU) |
| Other Features | |
| Special Features | 4x EZ Debug LED |
| Warranty Information | |
| Warranty | 3 Year warranty |
MSI PRO Z890-S WIFI LGA 1851 ATX Motherboard
The MSI PRO Z890-S WIFI LGA 1851 ATX Motherboard is a powerful and future-ready platform designed for professionals, content creators, AI workloads, and high-performance gaming PCs. Built on the Intel Z890 chipset, this motherboard supports Intel Core Ultra Series 2 processors and delivers exceptional performance, stability, and connectivity for demanding computing environments. Its professional design and advanced feature set make it an ideal choice for users seeking a reliable foundation for their next-generation desktop system.
Featuring support for DDR5 memory up to 256GB, the PRO Z890-S WIFI enables ultra-fast memory performance and improved system responsiveness. The motherboard supports memory overclocking and Intel XMP profiles, allowing users to maximize performance for gaming, content creation, and multitasking applications. The advanced power delivery system ensures stable operation even under heavy workloads.
For storage and expansion, the motherboard includes PCIe 5.0 support, multiple M.2 slots, and SATA connectivity, allowing users to build ultra-fast storage configurations. The PCIe 5.0 x16 slot provides maximum bandwidth for the latest graphics cards, making it suitable for gaming, rendering, AI computing, and professional applications.
Networking is equally impressive with integrated Wi-Fi 7, Bluetooth 5.4, and 2.5GbE LAN, delivering fast and reliable wired and wireless connectivity. The inclusion of Thunderbolt 4, USB 20Gbps Type-C, HDMI, and DisplayPort ensures excellent connectivity for modern peripherals and displays.
Whether you're building a professional workstation, gaming PC, or AI-powered system, the MSI PRO Z890-S WIFI offers the performance, expansion capability, and reliability required for next-generation computing.
Features of MSI PRO Z890-S WIFI LGA 1851 ATX Motherboard
- Intel Z890 chipset
- Supports Intel Core Ultra Series 2 processors
- LGA 1851 socket
- ATX form factor design
- 4 DDR5 memory slots supporting up to 256GB
- DDR5 memory overclocking support
- PCIe 5.0 x16 graphics slot
- Three M.2 storage slots
- Integrated Wi-Fi 7 and Bluetooth 5.4
- 2.5GbE high-speed LAN
- Thunderbolt 4 connectivity
- USB 20Gbps Type-C support
Why Choose MSI PRO Z890-S WIFI LGA 1851 ATX Motherboard?
The MSI PRO Z890-S WIFI is an excellent choice for users looking for a premium motherboard that combines performance, connectivity, and future-proof technology. With support for Intel Core Ultra processors, DDR5 memory, PCIe 5.0 expansion, and Wi-Fi 7 networking, it is ready for modern gaming, content creation, AI applications, and professional workloads. The robust power design, advanced cooling features, and extensive connectivity options ensure long-term reliability and upgrade flexibility. Whether you are building a powerful workstation or a high-end gaming PC, this motherboard provides the performance and features needed for years to come.
FAQ
Q1: Which processors are compatible with the MSI PRO Z890-S WIFI?
It supports Intel Core Ultra Series 2 desktop processors using the LGA 1851 socket.
Q2: Does this motherboard support DDR5 memory?
Yes, it supports DDR5 memory with capacities up to 256GB and advanced overclocking capabilities.
Q3: Does the motherboard include built-in Wi-Fi?
Yes, it comes with integrated Wi-Fi 7 and Bluetooth 5.4 for high-speed wireless connectivity.
