MSI MPG Z790 CARBON MAX WIFI II DDR5 ATX Motherboard

MSI MPG Z790 CARBON MAX WIFI II DDR5 ATX Motherboard
MSI MPG Z790 CARBON MAX WIFI II DDR5 ATX Motherboard
MSI MPG Z790 CARBON MAX WIFI II DDR5 ATX Motherboard
MSI MPG Z790 CARBON MAX WIFI II DDR5 ATX Motherboard
-16 %
MSI MPG Z790 CARBON MAX WIFI II DDR5 ATX Motherboard
MSI MPG Z790 CARBON MAX WIFI II DDR5 ATX Motherboard
MSI MPG Z790 CARBON MAX WIFI II DDR5 ATX Motherboard
MSI MPG Z790 CARBON MAX WIFI II DDR5 ATX Motherboard
MSI MPG Z790 CARBON MAX WIFI II DDR5 ATX Motherboard
47,500৳
56,500৳
Ex Tax: 47,500৳
EMI starts at 16,657৳/month. View all 26 banks EMI plans >
  • Stock: In Stock
  • Brand: MSI
  • Model: MPG Z790 CARBON MAX WIFI II

Key Features

    • Supported CPU: 14th/13th/12th Gen Core, Pentium Gold & Celeron Processor (LGA 1700)
    • Supported RAM: 4x DDR5, 7800+(OC), Max 256GB
    • Graphics Output: 1x HDMI2.1
    • Features: 5Gbps LAN with Wi-Fi 7 Solution
Contact for Bulk Quantity: 01771833944
অর্ডার করার পূর্বে কাস্টমার কেয়ার থেকে পন্যের স্টক ও ডেলিভারি সম্পর্কে জেনে নেয়ার অনুরোধ করা যাচ্ছে। প্রযুক্তি পণ্যের মূল্য অস্থিতিশীল হওয়ায় কারণে যেকোন মুহূর্তে যেকোন প্রযুক্তি পণ্যের মূল্য পরিবর্তন হতে পারে।
General Information
Type DDR5
Chipset Manufacturer Intel Z790 Chipset
Audio Feature Realtek ALC4080 Codec
7.1-Channel USB High Performance Audio
Supports up to 32-Bit/384 kHz playback on front panel
CPU Support Intel Core 14th/ 13th/ 12th Gen Processors, Intel Pentium Gold and Celeron Processors
LGA 1700
Form Factor ATX
243.84mmx304.8mm
Graphics Card 1x HDMI
Support HDMI 2.1, maximum resolution of 4K 60Hz
HDMI Port 1x HDMI 2.1
I/O Ports 1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x CPU Fan
1x Pump Fan
5x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x TBT connector (JTBT, supports RTD3)
3x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
1x ARGB+FAN Header (JAF_1)
1x USB4 card connector (JTBT_U4_1, supports RTD3)
4x USB 2.0 ports
2x USB 5Gbps Type A ports
1x USB 20Gbps Type C ports
LAN Realtek 5Gbps LAN
M.2 Socket 5x M.2 slots
Maximum Memory Supported 256GB
Memory 7800+(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz
PCI 2x PCI-E x16 slot
1x PCI-E x1 slot
PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)
RAID Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices
Slots 4 x UDIMM
Special Features LED FEATURE: 4x EZ Debug LED
Storage 5x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_2 Source (From CPU) supports up to PCIe 5.0 x4 , supports 22110/2280/2260 devices
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_5 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260 devices
6x SATA 6G
TPM (Trusted Platform Module ) 1x TPM pin header(Support TPM 2.0)
USB 4x USB 2.0 (Front)
2x USB 5Gbps Type A (Rear)
2x USB 5Gbps Type A (Front)
6x USB 10Gbps Type A (Rear)
1x USB 10Gbps Type C (Rear)
1x USB 20Gbps Type C (Rear)
1x USB 20Gbps Type C (Front)
Wireless Communication module Wi-Fi 7 Solution
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (320MHz) up to 5.8Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax
Supports Bluetooth 5.4, MLO, 4KQAM
Warranty Information
Warranty 3 years

MSI MPG Z790 CARBON MAX WIFI II DDR5 ATX Motherboard

MSI MPG Z790 CARBON MAX WIFI II DDR5 ATX Motherboard, a powerhouse of cutting-edge technology and performance. Designed to cater to the needs of hardcore gamers, content creators, and PC enthusiasts, this motherboard is a true marvel of engineering and innovation. At the heart of this exceptional motherboard lies the Intel Z790 Chipset, providing seamless compatibility with Intel Core 14th, 13th, and 12th Gen Processors, as well as Intel Pentium Gold and Celeron Processors, all fitting snugly into the LGA 1700 socket. The ATX form factor measures 243.84mmx304.8mm, offering a spacious layout for easy installation and optimal airflow within your PC case. Experience unparalleled audio fidelity with the Realtek ALC4080 Codec and 7.1-Channel USB High Performance Audio, supporting up to 32-Bit/384 kHz playback on the front panel, delivering an immersive audio experience for gaming, multimedia, and content creation. When it comes to expansion and connectivity, the MSI MPG Z790 CARBON MAX WIFI II doesn't disappoint. With 2x PCI-E x16 slots, 1x PCI-E x1 slot, and M.2 Socket with 5x M.2 slots, you have the freedom to customize your system with high-speed storage and future-proof expansion options. The DDR5 memory support with 4 x UDIMM slots allows for memory speeds of up to 7800MHz (OC), accommodating up to a staggering 256GB of memory. The graphics capabilities are equally impressive, featuring 1x HDMI 2.1 port with support for a maximum resolution of 4K at 60Hz, ensuring a visually stunning display for your gaming and multimedia needs. Connectivity is a breeze with a plethora of USB ports, including 4x USB 2.0 (Front), 2x USB 5Gbps Type A (Rear), 2x USB 5Gbps Type A (Front), 6x USB 10Gbps Type A (Rear), 1x USB 10Gbps Type C (Rear), 1x USB 20Gbps Type C (Rear), and 1x USB 20Gbps Type C (Front). The Realtek 5Gbps LAN and Wi-Fi 7 Solution with MU-MIMO technology ensure lightning-fast and reliable network connectivity. With support for multiple storage configurations, including 5x M.2 slots and 6x SATA 6G ports with RAID support, the MSI MPG Z790 CARBON MAX WIFI II offers unparalleled flexibility for your storage needs. In conclusion, the MSI MPG Z790 CARBON MAX WIFI II DDR5 ATX Motherboard is a technological marvel, combining top-notch performance, connectivity, and expandability, all backed by a 3-year manufacturing warranty, making it the perfect choice for building a high-end gaming or content creation PC.

MSI MPG Z790 CARBON MAX WIFI II DDR5 ATX Motherboard Features

  • Processor Support: The motherboard supports a wide range of Intel processors, including the Intel Core 14th, 13th, and 12th Gen Processors, as well as Intel Pentium Gold and Celeron Processors. This level of compatibility ensures that users have the flexibility to choose the processor that best suits their needs.
  • Expansion Slots: With 2x PCI-E x16 slots, 1x PCI-E x1 slot, and M.2 Socket with 5x M.2 slots, users have the freedom to expand their system with additional graphics cards, high-speed storage, and other expansion cards, delivering exceptional scalability for various configurations.
  • Memory Support: The motherboard supports DDR5 memory, offering 4 x UDIMM slots and a staggering maximum memory capacity of 256GB. The supported memory speeds range from 4800MHz to an impressive 7800MHz when overclocked, catering to the demands of memory-intensive applications and gaming.
  • Graphics and Connectivity: Featuring 1x HDMI 2.1 port with support for a maximum resolution of 4K at 60Hz, the motherboard ensures high-quality visual output. The extensive array of USB ports, including 4x USB 2.0 (Front), 2x USB 5Gbps Type A (Rear), 2x USB 5Gbps Type A (Front), 6x USB 10Gbps Type A (Rear), 1x USB 10Gbps Type C (Rear), and 1x USB 20Gbps Type C (Rear), offers seamless connectivity for a wide range of peripherals.
  • Wireless Communication: Equipped with the Wi-Fi 7 Solution, the motherboard supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (320MHz) up to 5.8Gbps, and Bluetooth 5.4, ensuring high-speed wireless connectivity and compatibility with the latest wireless standards.
  • Storage and RAID Support: The motherboard accommodates 5x M.2 slots, 6x SATA 6G ports, and supports RAID 0, RAID 1, RAID 5, and RAID 10 for both SATA storage devices and M.2 NVMe storage devices, offering versatile storage options and data redundancy.
  • Audio and Internal I/O Ports: With the Realtek ALC4080 Codec and 7.1-Channel USB High Performance Audio, users can enjoy exceptional audio performance. The internal I/O ports provide extensive connectivity options, including power connectors, fan connectors, RGB LED connectors, USB ports, and TPM headers, ensuring comprehensive support for various internal components and peripherals.
  • Special Features: The motherboard is equipped with special features, including 4x EZ Debug LED, enhancing system monitoring and troubleshooting.

In conclusion, the MSI MPG Z790 CARBON MAX WIFI II DDR5 ATX Motherboard stands out as a high-performance, feature-rich motherboard that offers exceptional compatibility, expansion options, connectivity, and reliability, making it an ideal choice for building a powerful and versatile PC system.
