Gigabyte Z890 AORUS ELITE WIFI7 Intel Motherboard

Gigabyte Z890 AORUS ELITE WIFI7 Intel Motherboard
Gigabyte Z890 AORUS ELITE WIFI7 Intel Motherboard
Gigabyte Z890 AORUS ELITE WIFI7 Intel Motherboard
-14 %
Gigabyte Z890 AORUS ELITE WIFI7 Intel Motherboard
Gigabyte Z890 AORUS ELITE WIFI7 Intel Motherboard
Gigabyte Z890 AORUS ELITE WIFI7 Intel Motherboard
Gigabyte Z890 AORUS ELITE WIFI7 Intel Motherboard

Discontinued

  • Stock: Discontinued
  • Brand: Gigabyte
  • Model: Z890 AORUS ELITE

Key Features

  • Intel® Z890 Express Chipset
  • I/O Controller: iTE® I/O Controller Chip
  • ATX Form Factor; 30.5cm x 24.4cm
  • Support for Windows 11 64-bi
Contact for Bulk Quantity: 01771833944
অর্ডার করার পূর্বে কাস্টমার কেয়ার থেকে পন্যের স্টক ও ডেলিভারি সম্পর্কে জেনে নেয়ার অনুরোধ করা যাচ্ছে। প্রযুক্তি পণ্যের মূল্য অস্থিতিশীল হওয়ায় কারণে যেকোন মুহূর্তে যেকোন প্রযুক্তি পণ্যের মূল্য পরিবর্তন হতে পারে।
General Information
Audio Realtek® ALC1220 CODEC
* The back panel line out jack supports DSD audio.


High Definition Audio
2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To configure 7.1-
channel audio, access the audio software for audio settings.


Support for S/PDIF Out
CPU LGA1851 socket: Support for Intel® Core™ Ultra Processors
L3 cache varies with CPU
* Please refer to "CPU Support List" for more information.
Form Factor ATX Form Factor; 30.5cm x 24.4cm
I/O Controller iTE® I/O Controller Chip
Internal I/O Connectors 1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
1 x CPU fan header
1 x CPU fan/water cooling pump header
3 x system fan headers
1 x system fan/water cooling pump header
3 x addressable RGB Gen2 LED strip headers
1 x RGB LED strip header
4 x M.2 Socket 3 connectors
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB Type-C® header, with USB 3.2 Gen 2 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI
V2 module only)
1 x HDMI port (Note)
1 x power button
1 x reset button
1 x Q-Flash Plus button
1 x reset jumper
1 x Clear CMOS jumper

(Note) Actual support may vary by CPU.
LAN Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Memory Support for DDR5 9200(O.C) / 9066(O.C) / 8933(O.C) / 8800(O.C) / 8600(O.C) / 8400(O.C) /
8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) /
7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400 / 6200 / 6000 / 5800 / 5600MT/s
memory modules.
4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system
memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
Support CUDIMM memory module
(The CPU and memory configuration may affect the supported memory types, data rate
(speed), and number of DRAM modules, please refer to "Memory Support List" for more
information.)
Onboard Graphics Integrated Graphics Processor-Intel® HD Graphics support:
- 1 x Intel® Thunderbolt™ 4 connector (USB4® USB Type-C® port), supporting DisplayPort and Thunderbolt™ video outputs
When a Thunderbolt™ monitor is installed, the maximum resolution supported is
5120x2880@60 Hz with 24 bpp (single display output).
When a USB4® USB Type-C® monitor is installed, the maximum resolution supported is
3840x2160@240 Hz (single display output).
* Because of the limited I/O resources of the PC architecture, the number of Thunderbolt™
devices that can be used is dependent on the number of the PCI Express
devices being installed. (Refer to Chapter 2-6, "Back Panel Connectors," for more
information.)
* Support for DisplayPort 2.1 version and HDCP 2.3


- 1 x front HDMI port, supporting a maximum resolution of 1920x1080@30 Hz
* Support for HDMI 1.4 version


- 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
* Support for DisplayPort 2.1 version and HDCP 2.3


(Graphics specifications may vary depending on CPU support.)
Support for up to triple-display at the same time
Operating System Support for Windows 11 64-bit
Storage Interface Chipset:
- 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB)
- 1 x M.2 connector (Socket 3, M key, type 22110/2280 SATA and PCIe 4.0 x4 SSD support)
(M2M_SB)
- 4 x SATA 6Gb/s connectors
RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices
RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
USB Chipset:
- 1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header
- 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
- 5 x USB 3.2 Gen 1 ports (3 ports on the back panel, 2 ports available through the internal USB header)

Chipset+2 USB 2.0 Hubs:
- 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
Wireless Communication module MediaTek Wi-Fi 7 MT7925 (PCB rev. 1.0)
- 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands
- BLUETOOTH 5.4
- Support for 11be 160MHz wireless standard
Realtek® Wi-Fi 7 RTL8922AE (PCB rev. 1.1)
- 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands
- BLUETOOTH 5.4
- Support for 11be 160MHz wireless standard
(Actual data rate may vary depending on environment and equipment.)
* Wi-Fi 7 features require Windows 11 SV3 to function properly. (There is no support driver for Windows 10.)
** Wi-Fi 7 channels on 6 GHz band availability depends on individual country's regulations.
Main Features
BIOS 1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Chipset Intel® Z890 Express Chipset
Physical Specification
Expansion Slots CPU:
- 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)
* The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card
is to be installed, be sure to install it in the PCIEX16 slot.


Chipset:
- 2 x PCI Express x16 slots, supporting PCIe 4.0 and running at x4 (PCIEX4_1, PCIEX4_2)

Gigabyte Z890 AORUS ELITE WIFI7 Intel Motherboard

Gigabyte Z890 AORUS ELITE WIFI7 Intel Motherboard is designed to provide high-performance capabilities for gaming and professional workstations. Equipped with an LGA 1851 socket, it supports the latest Intel® Core™ Ultra Processors, enabling seamless multitasking and superior computing power. The Intel® Z890 Express Chipset offers enhanced connectivity and storage solutions, making it an excellent choice for both casual gamers and content creators. This motherboard supports DDR5 memory with a variety of overclocking options, allowing for up to 256 GB of memory at speeds ranging from 6400 MT/s to 9200 MT/s. It features four DDR5 DIMM slots, enabling dual-channel memory architecture and compatibility with ECC Un-buffered DIMM and XMP memory profiles for faster and more stable performance. For graphical output, the Z890 AORUS ELITE comes with Intel® HD Graphics support, offering multiple display options such as Thunderbolt™ 4, HDMI, and DisplayPort for up to triple-display setup. It also supports high-resolution video outputs, ideal for immersive gaming or content editing. The motherboard provides Realtek® ALC1220 for high-definition audio with 7.1-channel support, ensuring clear sound quality for gaming and multimedia applications. For network connectivity, it features Realtek® 2.5GbE LAN and the latest Wi-Fi 7 standard (with Bluetooth 5.4), delivering fast and reliable wireless performance With PCIe 5.0 support, the board offers ample expansion options, including M.2 PCIe slots and SATA connectors for storage upgrades. The ATX form factor allows for flexibility in case compatibility, and advanced features like Q-Flash Plus and Smart Backup provide ease of use for system upgrades and maintenance. Overall, the Gigabyte Z890 AORUS ELITE WIFI7 motherboard is a top-tier choice for those seeking advanced performance, connectivity, and reliability.

Quick Compare

Product Details
Product Gigabyte Z890 AORUS ELITE WIFI7 Intel Motherboard ASUS Z890 AYW GAMING WIFI W LGA 1851 ATX Motherboard MSI MAG Z790 TOMAHAWK WIFI DDR5 Intel 12th and 13th Gen ATX Motherboard GIGABYTE Z790 AORUS ELITE AX 14th,13TH And 12TH GEN MOTHERBOARD
Image Gigabyte Z890 AORUS ELITE WIFI7 Intel Motherboard ASUS Z890 AYW GAMING WIFI W LGA 1851 ATX Motherboard MSI MAG Z790 TOMAHAWK WIFI DDR5 Intel 12th and 13th Gen ATX Motherboard GIGABYTE Z790 AORUS ELITE AX 14th,13TH And 12TH GEN MOTHERBOARD
Price 48,500৳ 41,500৳ 56,500৳ 42,300৳ 44,500৳ 42,700৳ 44,500৳ 40,000৳
Model Z890 AORUS ELITE Z890 AYW GAMING WIFI W MAG Z790 TOMAHAWK WIFI DDR5 Model
Brand Gigabyte Asus MSI Gigabyte
Availability Discontinued In Stock In Stock In Stock
Rating
Based on 0 reviews.

Based on 0 reviews.

Based on 0 reviews.

Based on 1 reviews.
Summary Gigabyte Z890 AORUS ELITE WIFI7 Intel MotherboardGigabyte Z890 AORUS ELITE WIFI7 Intel Motherboard is designed to provide high-performance capabilities for gaming and professional workstations. Equipped with an LGA 1851 socket, it supports the latest Intel® Core™ Ultra Processors, enabling seamless multitasking and superior computing power. The Intel® Z890 Express Chipset offers enhanced connectivity and storage solutions, making it an excellent choice for both casual gamers and content creators. This motherboard supports DDR5 memory with a variety of overclocking options, allowing for up to 256 GB of memory at speeds ranging from 6400 MT/s to 9200 MT/s. It features four DDR5 DIMM slots, enabling dual-channel memory architecture and compatibility with ECC Un-buffered DIMM and XMP memory profiles for faster and more stable performance. For graphical output, the Z890 AORUS ELITE comes with Intel® HD Graphics support, offering multiple display options such as Thunderbolt™ 4, HDMI, and DisplayPort for up to triple-display setup. It also supports high-resolution video outputs, ideal for immersive gaming or content editing. The motherboard provides Realtek® ALC1220 for high-definition audio with 7.1-channel support, ensuring clear sound quality for gaming and multimedia applications. For network connectivity, it features Realtek® 2.5GbE LAN and the latest Wi-Fi 7 standard (with Bluetooth 5.4), delivering fast and reliable wireless performance With PCIe 5.0 support, the board offers ample expansion options, including M.2 PCIe slots and SATA connectors for storage upgrades. The ATX form factor allows for flexibility in case compatibility, and advanced features like Q-Flash Plus and Smart Backup provide ease of use for system upgrades and maintenance. Overall, the Gigabyte Z890 AORUS ELITE WIFI7 motherboard is a top-tier choice for those seeking advanced performance, connectivity, and reliability... ASUS Z890 AYW GAMING WIFI W LGA 1851 ATX MotherboardThe ASUS Z890 AYW GAMING WIFI W LGA 1851 ATX Motherboard is a powerhouse built for gamers and PC enthusiasts who demand cutting-edge performance and versatility. Designed around the Intel Z890 chipset, it supports the latest Intel Core Ultra Processors (Series 2), ensuring compatibility with high-performance CPUs. Its ATX form factor offers ample space for advanced features, making it ideal for gaming rigs and content creation setups.This motherboard is equipped with DDR5 memory support, featuring four DIMM slots with a maximum capacity of 192GB. With support for speeds up to 9066+ MT/s (OC) and Intel Extreme Memory Profile (XMP), users can achieve unparalleled memory performance. Additionally, ASUS Enhanced Memory Profile III further enhances stability and overclocking capabilities. For storage, the Z890 offers four M.2 slots and four SATA 6Gb/s ports, providing extensive flexibility for high-speed SSDs and traditional drives. The M.2 slots support both PCIe 5.0 and 4.0 modes, ensuring blazing-fast data transfer speeds for demanding applications. Connectivity is exceptional, with Thunderbolt™ 4, Wi-Fi 6, and Bluetooth 5.3 ensuring seamless wireless communication. The board also features multiple USB 20Gbps and 10Gbps ports, including USB Type-C with power delivery for fast charging. The integrated Realtek 2.5Gb Ethernet port ensures ultra-fast and stable wired networking. Special features include ASUS Aura Sync RGB lighting, advanced thermal solutions with VRM heatsinks and M.2 heatsinks, and robust durability with 5X PROTECTION III. DIY enthusiasts will appreciate the EZ DIY tools such as BIOS FlashBack™, M.2 Q-Latch, and pre-mounted I/O shield. The ASUS Z890 AYW GAMING WIFI W delivers high-end gaming and productivity performance, making it an excellent choice for modern PC builds. Backed by a 3-year warranty, it ensures reliability and peace of mind... MSI MAG Z790 TOMAHAWK WIFI DDR5 13th Gen ATX Motherboard MSI's MAG Z790 TOMAHAWK WIFI DDR5 LGA 1700 ATX Motherboard provides seamless connectivity to your system. This ATX motherboard, which uses the Intel Z790 chipset and LGA 1700 socket, has four DDR5 RAM slots that allow twin-channel memory and speeds up to 5333 MHz when overclocked. Storage is abundant with seven SATA III and four M.2 connections that enable RAID 0, 1, 5, and 10. GPUs and other adaptor cards can be installed using PCIe 5.0 x16, PCIe 4.0 x16, and PCIe 3.0 x1 slots. Benefit from quick networking with a 2.5 GbE Intel LAN and Wi-Fi 6E; easily connect to wireless peripherals with Bluetooth 5.2. The Realtek ALC4080 audio codec offers 7.1 channel surround sound, and the rear ports can be used for analog or digital output. Connect connected peripherals to four USB 3.2 Gen 1 and four USB 3.2 Gen 2 Type-A ports, or to two USB 3.2 Gen 2 and two Type-C ports. DisplayPort and HDMI are used to output video. There are also Clear CMOS and Flash BIOS buttons on the back I/O panel. Front-panel USB 3.2 Gen 2 Type-C and USB 3.2 Gen 1 and 2.0 Type-A ports, RGB connections, chassis intrusion, a TPM module, and other features are supported through internal headers.FeaturesSupports Intel 12th and 13th Gen processorsDual DDR5 memory support, with up to 128GB capacityDual M.2 slots with PCIe 5.0 supportPCIe 5.0 and USB 4.0 supportAdvanced Thermal Design with Frozr Heatsink Design and M.2 Shield Frozr for enhanced coolingCore Boost and DDR5 Boost technology for stable power delivery and optimized memory performanceWi-Fi 6E (802.11ax) and Bluetooth 5.2 for high-speed wireless connectivityAudio Boost 5 with Nahimic 3 audio enhancer for immersive audio experienceMystic Light RGB LED lighting with various customization optionsMilitary-grade components and BIOS with MSI's exclusive Core Center for advanced tuning and monitoring... GIGABYTE Z790 AORUS ELITE AX 14th,13TH And 12TH GEN MOTHERBOARD GIGABYTE Z790 AORUS ELITE AX The Fast-Moving Technology Changes, GIGABYTE Always Follows The Latest Trends And Provides Customers With Advanced Features And Latest Technologies. GIGABYTE Motherboards Are Equipped With Upgraded Power Solution, Latest Storage Standards And Outstanding Connectivity To Enable Optimised Performance For Gaming.To Ensure Maximum Turbo Boost And Overclocking Performance Of Intel's New Generation CPU, GIGABYTE AORUS Series Motherboard Equip The Best VRM Design Ever Built With The Highest Quality Components.PCIe 5.0 Design Supports Double The Bandwidth Of PCIe 4.0 And Ensures That Compatible With Cutting-Edge SSDs And GPUs Released In The Next Few Years To Their Full Capability.AORUS Is Offering A Tested And Proven Platform That Has Memory Overclocking Capability Up To 7600 And Beyond. For DDR5 XMP Memory, All Users Need To Do To Attain High Memory Performance Boost Is To Ensure That Their Memory Module Is XMP Capable And That The XMP Function Is Activated And Enabled On Their AORUS Motherboard.The Exclusive 3 PCIe 4.0 M.2 From CPU And 2nd Generation 7000 MB/S SSD Provides Unparalleled Read/ Write Performance Up To 21053 And 15499 MB/S.GIGABYTE Motherboards Unparalleled Performance Is Guaranteed By Innovative And Optimised Thermal Design To Ensure The Best CPU, Chipset, SSD Stability And Low Temperatures Under Full Load Application And Gaming Performance   Key Features Support For 12th And 14th,13th Generation Intel Core Processors On Socket LGA 1700 Support For DDR5 7600 MHz Memory (OC) VRM 16+1+2 Phases (8+8 Parallel) PCI-Express 5.0 16x GIGABYTE Z790 AORUS ELITE AX  vs ASUS PRIME H610M-A D4 INFORMATION GIGABYTE Z790 AERO G ASUS PRIME H610M-A D4 CHIPSET Intel® Z790 Express Chipset Intel H610 Chipset FORM FACTOR ATX Form Factor mATX Form Factor 9.6 inch x 8.3 inch ( 24.4 cm x 21.1 cm ) LAN Realtek 2.5GbE LAN Chip (2.5 Gbps/1 Gbps/100 Mbps) 1 x Intel 1Gb Ethernet CPU LGA1700 Socket: Support For The 14th,13th And 12th Generation Intel® Core™, Pentium® Gold And Celeron® Processors L3 Cache Varies With CPU Intel Socket LGA1700 for 12th Gen Intel Core, Pentium Gold and Celeron Processors Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 ..
