ASUS ROG STRIX B760-I GAMING WIFI 13th Gen And 12th Gen Motherboard

ASUS ROG STRIX B760-I GAMING WIFI 13th Gen And 12th Gen Motherboard
ASUS ROG STRIX B760-I GAMING WIFI 13th Gen And 12th Gen Motherboard
ASUS ROG STRIX B760-I GAMING WIFI 13th Gen And 12th Gen Motherboard
-5 %
ASUS ROG STRIX B760-I GAMING WIFI 13th Gen And 12th Gen Motherboard
ASUS ROG STRIX B760-I GAMING WIFI 13th Gen And 12th Gen Motherboard
ASUS ROG STRIX B760-I GAMING WIFI 13th Gen And 12th Gen Motherboard
ASUS ROG STRIX B760-I GAMING WIFI 13th Gen And 12th Gen Motherboard
32,800৳
34,500৳
Ex Tax: 32,800৳
EMI starts at 11,502৳/month. View all 25 banks EMI plans >
  • Stock: In Stock
  • Brand: Asus
  • Model: ROG STRIX B760-I GAMING WIFI

Key Features

    • Intel B760 Chipset
    • Mini-ITX Form Factor
    • 1 x Intel 2.5Gb Ethernet
    • Memory: 2 x DIMM, Max. 96GB, DDR5
Contact for Bulk Quantity: 01771833944
অর্ডার করার পূর্বে কাস্টমার কেয়ার থেকে পন্যের স্টক ও ডেলিভারি সম্পর্কে জেনে নেয়ার অনুরোধ করা যাচ্ছে। প্রযুক্তি পণ্যের মূল্য অস্থিতিশীল হওয়ায় কারণে যেকোন মুহূর্তে যেকোন প্রযুক্তি পণ্যের মূল্য পরিবর্তন হতে পারে।
Main Features
BIOS 128 Mb Flash ROM, UEFI AMI BIOS
Chipset Intel® B760 Chipset
Form Factor Mini-ITX Form Factor
6.7 inch x 6.7 inch ( 17 cm x 17 cm )
Generel information
Accessories Cables
2 x SATA 6Gb/s cables
1 x ROG USB2.0 splitter cable
1 x Panel cable
Additional Cooling Kit
1 x Thermal pad for M.2
Miscellaneous
1 x ASUS Wi-Fi moving antennas
1 x Cable ties package
1 x M.2 Rubber Package
2 x Screw packages for M.2 SSD
1 x M.2 bracket
1 x ROG key chain
1 x ROG STRIX stickers
1 x ROG STRIX thank you card
Documentation
1 x User manual
Audio Feature SupremeFX Shielding Technology
Savitech SV3H712 AMP
Premium audio capacitors
BACK PANEL PORTS 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®)
4 x USB 3.2 Gen 1 ports (3 x Type-A +1 x USB Type-C®)
3 x USB 2.0 ports (3 x Type-A)
1 x HDMI® port
1 x DisplayPort
1 x Wi-Fi Module
1 x Intel® 2.5Gb Ethernet
5 x Audio jacks
CPU Intel Socket LGA1700 for 13th Gen Intel Core Processors & 12th Gen Intel Core, Pentium Gold and Celeron Processors
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0
Ethernet 1 x Intel® 2.5Gb Ethernet
ASUS LANGuard
Expansion Slots Intel® 13th & 12th Gen Processors
1 x PCIe 5.0 x16 slot
Graphic 1 x DisplayPort
1 x HDMI
Internal I/O Connectors Fan and Cooling related
1 x 4-pin CPU Fan header
1 x 4-pin Chasis Fan header
1 x 4-pin AIO Pump header
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
Storage related
2 x M.2 slots (Key M)
4 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 2 connector (supports USB Type-C®)
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1 x USB 2.0 headers support additional 2 USB 2.0 ports
Miscellaneous
1 x Addressable Gen 2 headers
1 x Aura RGB header
1 x Clear CMOS header
1 x Front Panel Audio header (AAFP)
1 x S/PDIF Out header
1 x Speaker header
1 x 10-1 pin System Panel header
1 x Thermal Sensor header
Manageability WOL by PME, PXE
Memory 2 x DIMM, Max. 96GB, DDR5
7600(OC)/ 7466(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/
6000(OC)/ 5800(OC)/ 5600/ 5400/ 5200/ 5000/ 4800 Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
OptiMem II
Operating System Windows® 11 64-bit, Windows® 10 64-bit
Software Features ROG Exclusive Software
- GameFirst VI
- ROG CPU-Z
- Sonic Studio III + Sonic Studio Virtual Mixer + Sonic Suite Companion
- Sonic Radar III
- DTS® Sound Unbound
ASUS Exclusive Software
Armoury Crate
- AIDA64 Extreme (60 days free trial)
- AURA Creator
- AURA Sync
- Fan Xpert 4
- Two-Way AI Noise Cancelation
- Power Saving
AI Suite 3
- Performance And Power Saving Utility
PC Cleaner
DIGI+ VRM
MyAsus
Norton 360 for Gamers
WinRAR
UEFI BIOS
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- ASUS UEFI BIOS EZ Mode
MemTest86
Special Features Extreme Engine Digi+
- 5K Black Metallic Capacitors
ASUS Q-Design
- M.2 Q-Latch
- Q-DIMM
- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
- Q-Slot
ASUS Thermal Solution
- M.2 heatsink backplate
ASUS EZ DIY
-CPU Socket lever protector
- ProCool
- Pre-mounted I/O shield
- SafeSlot
- SafeDIMM
AURA Sync
- Aura RGB header
- Addressable Gen 2 header
Storage Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports
Intel® 13th & 12th Gen Processors
M.2_1 slot (Key M), type 2260/2280 (supports PCIe 4.0 x4 mode)
Intel® B760 Chipset
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)
4 x SATA 6Gb/s ports
USB Rear USB (Total 8 ports)
1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®)
4 x USB 3.2 Gen 1 ports (3 x Type-A +1 x USB Type-C®)
3 x USB 2.0 ports (3 x Type-A)
Front USB (Total 5 ports)
1 x USB 3.2 Gen 2 connector (supports USB Type-C®)
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1 x USB 2.0 header supports additional 2 USB 2.0 ports
Wireless & Bluetooth Wi-Fi 6E
2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
Supports 2.4/5/6GHz frequency band
Bluetooth® v5.3

ASUS ROG STRIX B760-I GAMING WIFI 13th Gen And 12th Gen Motherboard

The ASUS ROG STRIX B760-I GAMING WIFI motherboard is a high-performance and feature-rich motherboard designed for 13th Gen Intel Core Processors and 12th Gen Intel Core, Pentium Gold, and Celeron Processors. It features a compact Mini-ITX form factor, measuring 6.7 inches by 6.7 inches, making it ideal for small form factor gaming and high-performance systems.

The motherboard is equipped with a powerful Intel B760 chipset and supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0, providing excellent processing power and performance. It has a 128 Mb Flash ROM with UEFI AMI BIOS, offering easy and intuitive system configuration and customization options.

The motherboard comes with a comprehensive set of accessories, including cables, additional cooling kit, ASUS Wi-Fi moving antennas, cable ties package, M.2 rubber package, and more. It also includes a user manual and documentation for easy installation and setup.

In terms of audio, the ASUS ROG STRIX B760-I GAMING WIFI motherboard features SupremeFX Shielding Technology, Savitech SV3H712 AMP, and premium audio capacitors, delivering immersive and high-quality sound for gaming and entertainment purposes.

The back panel of the motherboard offers a variety of connectivity options, including a USB 3.2 Gen 2x2 port (USB Type-C), USB 3.2 Gen 1 ports, USB 2.0 ports, HDMI and DisplayPort for video output, Wi-Fi module, Intel 2.5Gb Ethernet for fast and reliable networking, and audio jacks.

The motherboard supports a maximum of 96GB DDR5 memory with a dual-channel memory architecture, offering ample memory capacity for demanding applications and multitasking. It also supports Intel Extreme Memory Profile (XMP) and OptiMem II for optimized memory performance.

The ASUS ROG STRIX B760-I GAMING WIFI motherboard provides several software features and utilities, including ROG Exclusive Software such as GameFirst VI, ROG CPU-Z, Sonic Studio III, Sonic Radar III, and DTS Sound Unbound. It also includes ASUS Exclusive Software like Armoury Crate, AURA Creator, AURA Sync, Fan Xpert 4, and more, enhancing the overall user experience and customization options.

Features

  • Form Factor: The motherboard comes in a compact Mini-ITX form factor, measuring 6.7 inches x 6.7 inches (17 cm x 17 cm). This smaller size makes it suitable for building compact gaming rigs or HTPC (Home Theater PC) setups.
  • CPU Compatibility: It supports both 13th Gen Intel Core processors and 12th Gen Intel Core, Pentium Gold, and Celeron processors. This allows you to choose from a wide range of Intel CPUs to suit your performance needs.
  • Memory Support: The motherboard has 2 DIMM slots that support up to a maximum of 96GB of DDR5 memory. It supports various memory speeds, including overclocked frequencies, and features Dual Channel Memory Architecture and Intel Extreme Memory Profile (XMP) support for optimized memory performance.
  • Expansion Slots: It features a single PCIe 5.0 x16 slot, allowing you to install high-performance graphics cards or other expansion cards for added functionality.
  • Storage Connectivity: The motherboard provides two M.2 slots (Key M) and four SATA 6Gb/s ports for storage connectivity. The M.2 slots support PCIe 4.0 x4 mode, enabling faster data transfer speeds for NVMe SSDs. The SATA ports offer additional options for connecting traditional hard drives or SATA SSDs.
  • USB Connectivity: The rear panel of the motherboard offers a comprehensive selection of USB ports, including one USB 3.2 Gen 2x2 port (USB Type-C®), four USB 3.2 Gen 1 ports (three Type-A + one USB Type-C®), and three USB 2.0 ports (Type-A). Additionally, it has a front USB 3.2 Gen 2 connector and a USB 3.2 Gen 1 header for additional USB connectivity.
  • Networking: The motherboard features an Intel 2.5Gb Ethernet port for fast and reliable wired network connectivity. It also includes Wi-Fi 6E (802.11 a/b/g/n/ac/ax) with 2x2 configuration, supporting 2.4/5/6GHz frequency bands for high-speed wireless connectivity. Bluetooth v5.3 is also included for connecting wireless peripherals.
  • Audio: The audio section of the motherboard is equipped with SupremeFX Shielding Technology, Savitech SV3H712 AMP, and premium audio capacitors. These features deliver high-quality and immersive audio experiences for gaming and multimedia applications.

Overall, the ASUS ROG STRIX B760-I GAMING WIFI motherboard combines powerful performance, compact design, extensive connectivity options, and advanced features, making it an excellent choice for gamers and PC enthusiasts looking to build a high-performance system with the latest generation Intel processors.
